Woodward伍德沃德 9907-838 负载共享模块

Woodward伍德沃德 9907-838 负载共享模块

该装置被归类为伍德沃德负荷分配模块的一部分，编号为9907-838。9907-838 LSM型号旨在为其附属的工业发电机系统提供多种功能和调节能力。该装置配备了同步和下降负载共享。同步负载共享能够为发电机提供负载调整，即使两台或多台发电机并联。当实施空载和满载条件时，下降负载共享能够提供输出的减少。

规定的满载条件为3至7臂。9907-838装置配备有DC电源入口，电压范围为18至32伏/DC，最小值至最大值。该设备的环境规格使其工作温度范围在-40至70摄氏度或-40至158华氏度之间。它能够在11毫秒的锯齿脉冲下抵抗高达40 G的冲击。

9907-383设计有一套标准尺寸，便于安装到可接受的装置中。长10.77英寸，宽8.43英寸，高2.33英寸。这个装置的重量大约是3磅。将本机器安装在一个无湿气的区域以及一个主要无尘的区域是至关重要的。

The unit is classified as part of the Woodward Load Distribution Module and is numbered 9907-838. The 9907-838 LSM model is designed to provide a variety of functions and regulatory capabilities for its attached industrial generator system. The unit is equipped with synchronization and drop load sharing. Synchronous load sharing provides load adjustment for generators, even when two or more generators are in parallel. Descending load sharing can provide a reduction in output when no-load and full-load conditions are implemented.

The specified full load conditions are 3 to 7 arms. The 9907-838 unit is equipped with a DC power supply inlet with a voltage range of 18 to 32 volts /DC, minimum to maximum. The device's environmental specifications allow it to operate in a temperature range of -40 to 70 degrees Celsius or -40 to 158 degrees Fahrenheit. It is capable of resisting up to 40G of shock at a sawtooth pulse of 11ms.

The 9907-383 is designed in a standard size for easy installation into acceptable devices. It is 10.77 inches long, 8.43 inches wide and 2.33 inches high. The weight of this device is about three pounds. It is essential to install this machine in a moisture-free area as well as a predominantly dust-free area.
