SUGAHARA S-0000 REV.C抓住模块顶部和底部，将其从控制器。断开并拆除现有终端组件1.记录TA接线板上每条导线的标识和位置，然后断开每根导线。

2.按下终端组件下方的固定凸舌（多个凸舌对于双模块和三模块冗余版本），然后将终端组件向下。

3.取出终端组件配件并连接新终端组件1.将终端组件背面的固定夹插入I/O基本单元上的插槽。将终端组件压到底座上，然后滑动尽可能地组装。确保每个固定卡舌卡在印刷电路板上以进行设置终端组件就位。

将接线连接到螺钉接线板。应用最小值拧紧扭矩为0.5 Nm（0.37 ft.lb.）至端子螺钉。3.插入I/O模块（请参阅I/O模块安装程序）。操作和维护计划有助于确保功能安全可以在系统调试后进行维护。在役人员操作和维护通常不属于系统集成商可以提供指导和使用确保负责的人员或组织操作和维护可以使系统按规定运行安全级别。

Grab the module top and bottom and pull it from the controller. Disconnect and remove existing terminal components. 1. Record the identification and position of each cable on the TA terminal panel, and then disconnect each cable.

2. Press the fixed lugs under the terminal assembly (multiple lugs for dual and three-module redundant versions) and then push the terminal assembly down.

3. Take out the terminal assembly fittings and connect the new terminal assembly. 1. Insert the fixing clips on the rear of the terminal assembly into the slot on the I/O basic unit. Press the terminal assembly onto the base and slide to assemble as much as possible. Ensure that each fixed latch is clamped to the printed circuit board to set the terminal components in place.

Connect the wiring to the screw panel. Apply a minimum tightening torque of 0.5 Nm (0.37 ft.lb.) to the terminal screw. 3. Insert the I/O module (see I/O Module installation program). The operation and maintenance plan helps to ensure that functional safety can be maintained after the system is debugged. In-service personnel operation and maintenance is usually not part of the system integrator can provide guidance and use to ensure that the person or organization responsible for the operation and maintenance can make the system operate at the prescribed level of safety.
