SEU-211智能温控仪也是面向DCS应用的智能控制仪表，其控制对象是电加热炉，采用热电偶作为温度传感器；仪表的输入是热电偶信号，输出的晶闸管触发信号；通信功能方面，通信协议以RS-485为基础，采用地址呼叫/应答后互传数据帧的结构。

USTS-100智能仪表在设计时，硬件方面主要做了以下改进：

（1）使其测量输入/输出信号还可配接标准电压电流信号，并将多种信号的输入输出电路整合，形成一个能够兼顾不同电路结构和电路参数的输入输出电路，增强其通用性，还设计了被控对象模型系统，这样可以通过软件实现不同的工业过程控制对象的特性，增强DCS系统的应用能力。

（2）为实现复杂的控制算法，仪表微机预留了可扩展至32KB的掉电保护内存，可实现程序空间和数据空间的任意配置。

（3）通信部分电平转换的核心器件改用性能更好的MAX485。所以硬件电路的改进主要是增强仪表的适应性，通信功能的改进主要集中在软件方面。
