SCXI-1324 带有48个螺钉端子的高压接线端子

National Instruments SCX1-1324接线盒提供了一种连接和断开系统信号的便捷方法。该接线端子是大通道数温度或电压应用的理想解决

方案。

SCXI-1124是一款带有48个螺钉端子的高压接线端子，用于信号连接到SCXI-1160继电器模块。

NI SCXI-1324(部件号:777687-24)是高压通用开关应用的理想选择。该模型旨在与SCXI-1160继电器模块一起使用;它很容易安装到模块的前面。SCX/-1324是一种屏蔽接线端子，可实现快速、轻松的信号连接。SCX-1324高压接线盒上的48个螺丝端子连接到SCX1-1160继电器模块内部的16个继电器。与某些其他SCXI接线端子不同，该型号没有冷端传感器。SCX11324的共模隔离通道到通道和通道到地的电压均为250VRMS。该设备每个通道的负载或信号电流大为2A。

当用户准备好将Nl SCX/-1324连接到SCX-1160时，他们需要一些其他物品。需要AN SCX机箱、剪线钳、电线绝缘剥线钳、长嘴钳、1/8

英寸平头螺丝刀以及1号和2号飞利浦头螺丝刀。一旦这些项目准备就绪，用户就可以将模块前连接器连接到高压螺钉接线端子上的适当连接器。然后，用户可以拧紧SCXI-1324后部顶部和底部的指旋螺钉，以确保其固定到位。

如果用户想清洁对于National Instruments SCXIl1324 Terminal Block，好先使用柔软的非金属刷子清除模型上的灰尘。用户可以使用去

离子水和坚固的非金属刷子清除接线端子上的其他污染物。在将SCXI-1324恢复运行之前，应将其完全干燥并清除所有污染物。

SCXI-1324 带有48个螺钉端子的高压接线端子

The National Instruments SCX1-1324 junction box provides a convenient way to connect and disconnect system signals. The terminals are ideal for large channel number temperature or voltage applications

Plan.

The SCXI-1124 is a high voltage terminal with 48 screw terminals for signal connection to the SCXI-1160 relay module.

The NI SCXI-1324(Part number :777687-24) is ideal for high-voltage general-purpose switch applications. The model is intended for use with the SCXI-1160 relay module; It is easy to install to the front of the module. The SCX/-1324 is a shielded terminal that enables fast and easy signal connection. The 48 screw terminals on the SCX-1324 high voltage junction box are connected to the 16 relays inside the SCX1-1160 relay module. Unlike some other SCXI terminals, this model does not have a cold end sensor. The SCX11324 has a common mode isolated channel-to-channel and channel-to-ground voltage of 250VRMS. The device has a load or signal current of up to 2A per channel.

When users are ready to connect the Nl SCX/-1324 to the SCX-1160, they need a few other items. AN SCX case, wire cutters, wire insulation strippers, long nose pliers, 1/8 are required

Inch flat head screwdrivers and size 1 and 2 Philips head screwdrivers. Once these items are ready, the user can connect the module front connector to the appropriate connector on the high pressure screw terminal. The user can then tighten the finger screw on the top and bottom of the rear SCXI-1324 to ensure that it is secured in place.

If the user wants to clean the National Instruments SCXIl1324 Terminal Block, it is best to use a soft non-metallic brush to remove dust from the model. Users can use to go

Ionized water and a sturdy, non-metallic brush remove other contaminants from the terminals. SCXI-1324 should be completely dried and all contaminants removed before returning it to service.
