这PCI-5421是一个任意波形发生器 设备从国家文书。这PCI-5421设备有三种版本，板载内存大小有三种选择。零件号码778692-01拥有8 MB板载内存,零件号码778692-02具有32 MB板载内存，并且 零件号码778692-03拥有256 MB板载内存。该器件用于产生用户定义的任意波形。这PCI-5421设备也可以产生标准正弦、斜坡、三角和方波信号。为了精确产生波形PCI-5421利用直接数字合成(DSS)。该器件也可用于数据流和高级同步。

这PCI-5421附带一个模拟输出通道，有一个SMB(插孔)连接器。输出通道的DAC分辨率为16位。它是DC耦合型。输出端的通道PCI-5421设备可以组合相似路径中的波形。这意味着该器件支持波形求和。因此，可以连接不同模块的输出端子。这PCI-5421波形发生器 设备最大带宽为43 MHz。该器件具有一个7极椭圆滤波器。

这PCI-5421波形发生器 设备带有两个双向通道。用户可以对这些进行编程。这些通道有SMB(插孔)型连接器。这些频道的频率范围是DC到105兆赫。作为输入，这些通道被用作触发通道。最大输入过载为-2至+7 V电压。这些通道也可以用作事件发生器的输出。

PCI-5421 NI任意波形发生器

This PCI-5421 is an arbitrary waveform generator device from the state instrument. The PCI-5421 device comes in three versions, with three options for on-board memory sizes. Part number 778692-01 has 8 MB of on-board memory, part number 778692-02 has 32 MB of on-board memory, and part number 778692-03 has 256 MB of on-board memory. The device is used to generate arbitrary waveforms defined by the user. This PCI-5421 device can also generate standard sine, ramp, triangle, and square wave signals. To accurately generate the waveform PCI-5421 utilizes direct digital synthesis (DSS). The device can also be used for data streaming and advanced synchronization.

This PCI-5421 comes with an analog output channel with an SMB(jack) connector. The DAC resolution of the output channel is 16 bits. It is DC coupled. The output channel PCI-5421 device can combine waveforms in similar paths. This means that the device supports waveform summation. Therefore, the output terminals of different modules can be connected. This PCI-5421 waveform generator device has a maximum bandwidth of 43 MHz. The device has a 7-pole elliptic filter.

This PCI-5421 waveform generator device has two two-way channels. Users can program these. These channels have SMB(jack) type connectors. The frequency range of these channels is DC to 105 MHZ. As input, these channels are used as trigger channels. The maximum input overload is -2 to +7 V voltage. These channels can also be used as the output of an event generator.
