MOTOROLA IPMC712 提供后置I/O板卡

四个串行端口（两个或三个异步和一个或两个同步/同步，取决于模块)安装了IPMC后，仍有一个PMC插槽可用、提供对OEM产品定制的支持。P2 I/O模式MVME5500系列支持两种可通过跳线配置的P2 I/O模式： PMC模式和IPMC模式。

PMC模式向后兼容MVME2300/MVME2400和MVME5100的PMC模式。MVME2400和MVME5100在PMC模式下向后兼容。在PMC模式下，PMC插槽1的64个引脚和PMC插槽2的46个引脚可用于PMC后部I/O在PMC模式下，PMC插槽1的64个引脚和PMC插槽2的46个引脚可用于PMC后部I/O。

在IPMC模式下，MVME5500系列支持传统的MVME761或MVME712M I/O模块（具有有限的当IPMC761或IPMC712 PMC卡插入PMC插槽1时，MVME5500系列支持传统的MVME761或MVME712M I/O模块（具有有限的PMC I/O）。当IPMC761或IPMC712 PMC卡被装入PMC插槽1时。在这种配置中，PMC在这种配置中，PMC 2槽包含一些信号，这些信号被保留给扩展SCSI。

MOTOROLA IPMC712 提供后置I/O板卡

After four serial ports (two or three asynchronous and one or two synchronous/synchronous, depending on the module) are installed with IPMC, there is still a PMC slot available to provide support for OEM product customization. P2 I/O mode MVME5500 series supports two P2 I/O modes that can be configured by jumpers: PMC mode and IPMC mode.

The PMC mode is backward compatible with the PMC mode of MVME2300/MVME2400 and MVME5100. MVME2400 and MVME5100 are backward compatible in PMC mode. In PMC mode, 64 pins of PMC slot 1 and 46 pins of PMC slot 2 can be used for PMC rear I/O. In PMC mode, 64 pins of PMC slot 1 and 46 pins of PMC slot 2 can be used for PMC rear I/O..

In IPMC mode, MVME5500 series supports the traditional MVME761 or MVME712M I/O module (with limited PMC I/O). When the IPMC761 or IPMC712 PMC card is loaded into PMC slot 1. In this configuration, PMC in this configuration, the PMC 2 slot contains some signals, which are reserved for the expansion SCSI.
