IPMC761-001控制模块工控备件

IPMC761-001控制模块工控备件

IPMC761-001“WDT Enable”位用于启用看门狗定时器功能。此位必须设置为“1”以使看门狗定时器工作。注意，由于所有寄存器重置后默认为零，重置后始终禁用看门狗计时器。

这个在按顺序重置后，应用软件必须重新启用看门狗计时器使看门狗计时器继续运行。一旦看门狗定时器启用，应用软件必须在选定的超时内刷新看门狗计时器防止产生或SERR的时间。看门狗计时器执行对WDT Keepalive寄存器（WKPA）的写入来刷新。数据书面材料无关紧要。

启用时，通过写入阻止看门狗计时器重置系统至WDT保持寄存器（WKPA），位于中地址的偏移量0x0C处BAR2在选定的超时时间内。写入此位置的数据为无关的VMIVME-7750提供32KB的非易失性SRAM。此内存是映射在32K的地址空间中，从BAR1中的地址开始。此内存是随时可用，支持从PCI总线。当电路板的电源被切断时，该内存的内容被保留远离的。

IPMC761-001 The WDT Enable bit is used to enable the watchdog timer function. This bit must be set to "1" for the watchdog timer to work. Note that since all registers default to zero after reset, the watchdog timer is always disabled after reset.

After this is reset in order, the application must re-enable the watchdog timer for the watchdog timer to continue running. Once the watchdog timer is enabled, the application must refresh the time during which the watchdog timer prevents generation or SERR within the selected timeout. The watchdog timer performs a write to the WDT Keepalive register (WKPA) to refresh. Data paperwork is irrelevant.

When enabled, reset the system by writing the Block Watchdog timer to the WDT Hold Register (WKPA), located at the address offset 0x0C at BAR2 within the selected timeout period. Data written to this location provides 32KB of non-volatile SRAM for the unrelated VMIVME-7750. This memory is mapped in a 32K address space, starting with the address in BAR1. This memory is readily available, supported from the PCI bus. When the power to the board is cut off, the contents of the memory are kept away.
