威达蓄电池HX6-2.3

威达蓄电池HX6-2.3

威达蓄电池产品特性

额定电压:12V

额定容量(20hr):17Ah

外形尺寸:长:181mm 宽:77mm 高:167mm 总高:167mm

参考重量:约5.32Kg

不同放电率实际容量

20小时率:17Ah

10小时率：15.9Ah

5小时率：14.6Ah

1小时率：10.2Ah

15分钟率：6.5Ah

容量与温度的关系（20小时率）

40℃(104℉)：103%

25℃(77℉)：99.99%

0℃(32℉)：86%

－15℃(5℉)：65%

在25℃(77℉)时完全充电的内阻：约15.1mΩ

充电方法（恒压）

循环：更大充电电流为4.25A

充电电压14.5-15.0V/12V77℉(25℃)

充电温度补偿电压 -24mV/℃

浮充：更大充电电流为4.25A

充电电压13.6-13.8V/12V77℉(25℃)

充电温度补偿电压 -18mV/℃

威达蓄电池HX6-2.3

Vida battery product features

Rated voltage :12V

Rated capacity (20hr):17Ah

Dimensions: Length :181mm Width :77mm height :167mm Total height :167mm

Reference weight: about 5.32Kg

Actual capacity of different discharge rates

20 hour rate :17Ah

10-hour rate: 15.9Ah

5 hour rate: 14.6Ah

1 hour rate: 10.2Ah

15 minute rate: 6.5Ah

Capacity and temperature (20 hour rate)

40 ° C (104 ° F) : 103%

25 ° C (77 ° F) : 99.99%

0 ° C (32 ° F) : 86%

-15℃(5℉) : 65%

Internal resistance to full charge at 25 ° C (77 ° F) : approximately 15.1mΩ

Charging method (constant voltage)

Cycle: Higher charging current is 4.25A

Charging voltage 14.5-15.0V/12V77 ° F (25 ° C)

Charging temperature compensation voltage -24mV/℃

Floating charge: The higher charging current is 4.25A

Charging voltage 13.6-13.8V/12V77 ° F (25 ° C)

Charging temperature compensation voltage -18mV/℃
