IS220PSCAH1A 336A4940CSP9 串行通信输入/输出模块

IS220PSCAH1A 336A4940CSP9 串行通信输入/输出模块

IS220PSCAH1A I/O 包用于串行 Modbus 通信。该套件专为通用电气的 Mark VIeS 控制系统而设计。当使用这个包时，它可以提供最多两个输入输出以太网网络和一个串行通信板之间的接口。该板有六个可单独配置的串行收发器通道，可用于 RS485 半双工、RS232 和 RS422 标准。为 PSCA 电池组供电所需的输入通过三针电源输入和双 RJ45 以太网连接器发送。

IS220PSCAH1A 包上有一个串行 Modbus 主站服务，它具有许多不同的功能，其中一些功能如下：

RTU

数据位：七、八

32 位数据字排序

奇偶校验：偶数、无、奇数

车站地址

这些功能用于 PSCA 包上的六个可配置端口。可以在端口级别完成配置。有了 PSCA，包装上的两个以太网端口可用于帮助支持以太网 Modbus 主协议；请注意，只有在单工网络上使用时才会出现此配置。

IS220PSCAH1A 包具有执行自诊断测试的能力，其中之一是监控模拟输入，监控位置和压力以检查可配置的高电平和低电平。这些限制用于启用和禁用功能、锁定/非锁定以及生成警报。可能出现的一些警报是 32-67、114-119、108-113 和 72-107。所有这些警报都指示不同的错误。

IS220PSCAH1A 336A4940CSP9 串行通信输入/输出模块

The IS220PSCAH1A I/O package is used for serial Modbus communication. The kit is designed for General Electric's Mark VIeS control system. When used, this package can provide an interface between up to two input-output Ethernet networks and a serial communication board. The board has six individually configurable serial transceiver channels available for RS485 half-duplex, RS232 and RS422 standards. The input needed to power the PSCA battery pack is sent via a three-pin power input and dual RJ45 Ethernet connector.

There is a serial Modbus master service on the IS220PSCAH1A package, which has many different features, some of which are as follows:

RTU

Data bits: seven, eight

32-bit data word sort

Parity check: even, none, and odd

Station address

These functions are used for the six configurable ports on the PSCA package. This can be done at the port level. With PSCA, two Ethernet ports on the packaging can be used to help support the Ethernet Modbus master protocol; Note that this configuration occurs only when used on a simplex network.

The IS220PSCAH1A package has the ability to perform self-diagnostic tests, one of which is to monitor analog inputs, monitor position and pressure to check for configurable high and low levels. These restrictions are used to enable and disable features, lock/unlock, and generate alerts. Some of the possible alerts are 32-67, 114-119, 108-113, and 72-107. All of these alerts indicate different errors.
