IS200TBCIH1BBC 控制工业环境中燃气轮机和蒸汽轮机

IS200TBCIH1BBC是一种被称为接触端子板的装置。这是为Mark VI系列设计的PCB。Mark VI系列是通用电气公司(GE)制造的Mark系列中的一个系列。开发这些系统是为了控制工业环境中燃气轮机和蒸汽轮机的所有操作。

IS200TBCIH1BBC是一个长电路板，带有各种不同的电子元件。两(2)个非常大的纯黑色端子占据了IS200TBCIH1BBC的左半部分。这些端子板具有四十八(48)个由银金属制成的端子。

这些端子由从1到48的一系列数字标识，每个端子板中有24个。IS200TBCIH1BBC的右侧是一长串圆形电容器。这些电容器是纯红色的。这些电容器中有二十五(25)个与这些端子板相邻排列。IS200TBCIH1BBC的右边缘是三个银色和黑色的插孔连接器端口。

每个连接器端口的右侧是一个非常小的集成电路，标有字母u。另外两(2)个白色连接器位于IS200TBCIH1BBC顶部的中央。这两个连接器都包含三(3)个端口，可用于将其他组件连接到IS200TBCIH1BBC。PCB中心右侧有一条很长的微小电阻线。这条线几乎跨越了is 200 BCI h1 BBC的整个长度。

IS200TBCIH1BBC 控制工业环境中燃气轮机和蒸汽轮机

The IS200TBCIH1BBC is a device called a contact terminal board. This is a PCB designed for the Mark VI series. The Mark VI series is a series of Mark series manufactured by General Electric Company (GE). These systems were developed to control all operations of gas and steam turbines in industrial environments.

IS200TBCIH1BBC is a long circuit board with a variety of different electronic components. Two (2) very large pure black terminals occupy the left half of the IS200TBCIH1BBC. These terminal boards have forty-eight (48) terminals made of silver metal.

These terminals are identified by a series of numbers from 1 to 48, with 24 in each terminal board. On the right side of the IS200TBCIH1BBC is a long series of circular capacitors. These capacitors are pure red. Twenty-five (25) of these capacitors are arranged adjacent to these terminal plates. On the right edge of the IS200TBCIH1BBC are three silver and black jack connector ports.

To the right of each connector port is a very small integrated circuit labeled with the letter u. The other two (2) white connectors are located in the center of the top of the IS200TBCIH1BBC. Both connectors contain three (3) ports that can be used to connect other components to the IS200TBCIH1BBC. There is a long, tiny resistance line on the right side of the PCB center. This line spans almost the entire length of is 200 BCI h1 BBC.
