功能描述

该套件最多可控制 12 个继电器并接受来自端子板的反馈。有磁继电器（TRLYH1B、C、D 和 F 端子板）和固态继电器（TRLYH1E 板）可供选择。该套件由三针电源输入和两个 RJ45 以太网连接器供电。输出通过直接连接到相关端子板连接器的 DC-37 针连接器进行。LED 指示灯提供视觉诊断，红外端口可进行本地诊断串行通信。

兼容性

它可与六种不同类型的离散（继电器）输出端子板配合使用，包括 TRLY 和 SRLY 板，但不适用于 DIN 导轨安装的 DRLY 板。信号路径中使用的 I/O 包的数量称为控制模式：

Simplex 采用单个 I/O 包和一个或两个网络连接。

Dual 采用两个 I/O 包以及一个或两个网络接口。

TMR 采用三个 I/O 包，每个包都有一个网络连接。

IS220PDOAH1A安装

安装 PDOA 包：

牢固地安装所选的端子板。

将一个单工 PDOA I/O 包或三个 TMR PDOA I/O 包直接插入端子板连接器。

使用以太网端口旁边的螺柱以机械方式固定电池组。这些螺柱安装在端子板专用的安装支架上。支架的放置位置应确保电池组和端子板之间的 DC37 连接器不会受到直角力的影响。在产品的使用寿命内只需进行一次调整。

根据系统配置，连接一根或两根以太网电缆。该包适用于任一端口。使用双连接时，通常的做法是将 ENET1 连接到与 R 控制器关联的网络。

插入电池组侧面的连接器，将电池组连接到电源。该连接器不需要在电源与电缆断开的情况下插入，因为 I/O 包具有固有的软启动功能，可以控制电源应用中的电流浪涌。

IS220PDOAH1A 3364940CSP2 欧美备件 SIS系统 DCS模块

Function description

The kit controls up to 12 relays and accepts feedback from the terminal board. Magnetic relays (TRLYH1B, C, D and F terminal boards) and solid state relays (TRLYH1E boards) are available. The kit is powered by a three-pin power input and two RJ45 Ethernet connectors. Output is done via a DC-37 pin connector connected directly to the associated terminal board connector. The LED indicator provides visual diagnosis, and the infrared port allows serial communication for local diagnosis.

compatibility

It works with six different types of discrete (relay) output terminal boards, including TRLY and SRLY boards, but not DRLY boards mounted on DIN rails. The number of I/O packets used in the signal path is called the control mode:

Simplex uses a single I/O packet and one or two network connections.

Dual uses two I/O packets and one or two network interfaces.

TMR uses three I/O packets, each with a network connection.

The IS220PDOAH1A is installed

To install the PDOA package:

Securely install the selected terminal plate.

Plug one simplex PDOA I/O packet or three TMR PDOA I/O packets directly into the terminal board connector.

The battery pack is mechanically secured using studs next to the Ethernet port. These studs are mounted on a mounting bracket dedicated to the terminal board. The bracket should be positioned so that the DC37 connector between the battery pack and the terminal board is not affected by a straight Angle. Only one adjustment is required during the service life of the product.

Connect one or two Ethernet cables, depending on the system configuration. This package is available on any port. When using dual connections, it is common practice to connect ENET1 to the network associated with the R controller.

Insert the connector on the side of the battery pack to connect the battery pack to the power supply. The connector does not need to be plugged in when the power supply is disconnected from the cable, as the I/O package has an inherent soft-start function to control electrical surges in power applications.
