GE 通用电气 IS230TNCIH4C 交流线路滤波器

GE 通用电气 IS230TNCIH4C 交流线路滤波器

IS230TNCIH4C板由通用电气公司作为印刷电路板销售。该电路板可以安装在十三个或二十一个VME插槽式机架中。当在单工体系结构类型的系统中使用时，它通常会与控制模块一起使用，但如果选择的体系结构是三重冗余的，它将与IONet、主处理器卡和控制模块一起一起使用。

TNCI模型可用于两种主要通信类型，即单元数据高速公路（一种基于以太网的LAN通信类型）和IONet通信。请注意，UDH通信驱动程序通常与Mark VI系统内的主处理器卡相关联。

虽然IS230TNCIH4C板由十几个电容器、电阻器甚至更多的小部件组成，但该型号的主要视觉部件是两个接线板、三个sub-D引脚连接器、两个母插头型连接器和金属氧化物变阻器。

GE 通用电气 IS230TNCIH4C 交流线路滤波器

The IS230TNCIH4C board is marketed by General Electric as a printed circuit board. The board can be installed in thirteen or twenty-one VME slot type racks. When used in a simplex architecture type system, it will usually be used with a control module, but if the architecture chosen is triple redundant, it will be used with IONet, the main processor card, and the control module.

The TNCI model can be used for two main types of communication, namely cell data superhighway (an Ethernet-based LAN type of communication) and IONet communication. Note that UDH communication drivers are usually associated with the main processor card within the Mark VI system.

Although the IS230TNCIH4C board consists of more than a dozen small components of capacitors, resistors and even more, the main visual components of this model are two patch boards, three sub-D pin connectors, two female plug type connectors, and metal oxide rheostat.
