产品介绍

型号名称：IS200TPROH1C模拟量输出模块

IS200TPROH1C 适用于各种电气系统，电镀，电解行业中的交流大电流的测量和控制，该产品有以下几个特点：

●产品输入无饱和：由于产品采用的是rogowski原理，摒弃了传统的互感器原理或是霍尔原理中必须使用的磁芯，从而使得产品的输入范围可以做到很大而不影响产品的性能；

● 响应时间快：本产品响应时间可以达到us级别，可应用于电力系统中的故障录波等方面；

● 产品频响宽：本产品的频宽范围可以达到20khz以上，可广泛应用于输入波形复杂等信号检测；

● 产品线性好：产品输出的线性度可以达到0.2%，可以的反映输入信号的大小；

● 产品精度高：产品整体的精度在1%以内；

● 产品体积小，重量轻：相比传统的互感器原理和霍尔原理的产品，在相同输入量程的条件下，本产品的体积更小，重量更轻；

二、型号说明

三、主要技术指标

额定输入 0～20 kaac

额定输出 0～20 madc, 0～5 vdc, 4～20 madc;

精度 1.0级

线性范围 0～120%

隔离耐压 5000vdc/1分钟

辅助电源 +12vdc,±12vdc,+24vdc

工作温度 -20℃～+60℃

温度漂移 <300ppm/℃

GE 通用电气 IS200TPROH1C 数据采集系统架构

Product introduction

Model name: IS200TPROH1C Analog output module

IS200TPROH1C is suitable for all kinds of electrical systems, electroplating, electrolysis industry AC high current measurement and control, the product has the following characteristics:

● Product input saturation: Because the product adopts the rogowski principle, abandoning the traditional transformer principle or the Hall principle must be used in the magnetic core, so that the product input range can be very large without affecting the performance of the product;

● Fast response time: the response time of this product can reach us level, which can be applied to the fault recording of the power system;

● Product frequency response width: the product's bandwidth range can reach more than 20khz, can be widely used in the input waveform complex signal detection;

● Good product linearity: the linearity of product output can reach 0.2%, which can reflect the size of the input signal;

● High product accuracy: the overall accuracy of the product is within 1%;

● Small volume, light weight: compared with the traditional transformer principle and Hall principle products, under the same input range, the product is smaller in volume and lighter in weight;

2. Model description

3. Main technical indicators

Rated input 0 ~ 20 kaac

Rated output 0 ~ 20 madc, 0 ~ 5 vdc, 4 ~ 20 madc;

Accuracy level 1.0

Linear range 0 ~ 120%

Isolated voltage 5000vdc/1 min

Auxiliary power supply +12vdc,±12vdc,+24vdc

Operating temperature -20℃ ~ +60℃

Temperature drift <300ppm/℃
