IC694MDL940 RX3i分立式输出模块

IC694MDL940 RX3i分立式输出模块

该IC694MDL940是 PACSystem RX3i 分立式输出模块，以前由 GE Fanuc 制造，现在隶属于艾默生自动化。

 该模块具有十六 (16) 个常开 (N.O.) 触点，分为四 (4) 个，每组有四 (4) 个输出。  每个触点输出可在 5-30 VDC 下运行，标称电压为 24 VDC;5 - 250VAC，频率为 47 至 63 Hz，标称输入电压为 120/240VAC。  每个通道设计用于 2 安培的导频负载、每个输出的最大负载和每个公共端的最大负载 4 安培。

该模块的电流消耗为 7 mA，所有输出均由背板上的 5 V 总线接通，背板上的继电器 135V 总线接通所有输出时，电流消耗为 24 mA。  该IC694MDL940是艾默生自动化 PACSystem RX16i 系列的十六 (3) 点继电器输出模块，以前由 GE 智能平台 (GE IP) 制造。  该模块具有单插槽宽度，占用背板的单个插槽，并带有四 (4) 组输出，每组有四 (4) 个继电器输出。

  IC694MDL940继电器触点是常开 (N.O.) 触点或 A 型触点。每个输出触点的额定最大负载为 2 安培的先导负载，  每个输出的最大负载为最大值，而每个输出组设计为提供 4 安培的最大输出电流。  此外，该模块的最小负载为 10 mA，最大浪涌电流为 5 安培。每个继电器输出通道的响应时间为 15 ms，  两个信号转换的最大值，模块的功耗为 7 mA @ 5VDC 总线电压，背板上的继电器 135V 总线的功耗为 24 mA。

IC694MDL940 RX3i分立式输出模块

The IC694MDL940 is a PACSystem RX3i discrete output module formerly manufactured by GE Fanuc and now owned by Emerson Automation.

The module has sixteen (16) normally open (N.O.) contacts, divided into four (4) with four (4) outputs per group. Each contact output can operate at 5-30 VDC with a nominal voltage of 24 VDC; 5-250VAC, frequency 47 to 63 Hz, nominal input voltage 120/240VAC. Each channel is designed for pilot loads of 2 amps, maximum loads per output, and maximum loads of 4 amps per common end.

The current consumption of the module is 7 mA, all outputs are connected by the 5V bus on the backplane, and the current consumption is 24 mA when the relay 135V bus on the backplane is connected to all outputs. The IC694MDL940 is a sixteen (3) point relay output module in the Emerson Automation PACSystem RX16i family, previously manufactured by GE Intelligence Platforms (GE IP). The module has a single slot width, occupies a single slot in the backplane, and comes with four (4) sets of outputs, each with four (4) relay outputs.

The IC694MDL940 relay contacts are normally open (N.O.) contacts or A-type contacts. Each output contact is rated for a maximum 2 amp pilot load, each output for a maximum load, and each output group is designed to provide a maximum output current of 4 amps. In addition, the module has a minimum load of 10 mA and a maximum inrush current of 5 amps. The response time of each relay output channel is 15 ms, the maximum of the two signal conversion, the power consumption of the module is 7 mA @ 5VDC bus voltage, and the relay 135V bus on the backplane is 24 mA.
