IS210BPPBH2CAA型号用于Mark VI涡轮机控制系统，设计为印刷电路板。Mark VI系统中使用的BPPB板的一个主要特点是，它可以用于两种类型的涡轮原动机，即蒸汽涡轮或燃气涡轮。该模块的主要部件是八个母插头连接器，连接器的范围从两个到十八个插脚连接器。在板的左侧排成一行，有六个金属氧化物变阻器。

当模型安装在涡轮机控制系统中时，它将位于主控制模块中，它也有可能与备用保护模块一起使用。当在主控制模块中时，有许多软件维护工具。维护工具从保护算法到排序和I/O显示各不相同。

IS210BPPBH2CAA型号配有一个操作员界面，该界面被称为HMI或人机界面。该界面被设计为微软视窗NT个人电脑操作系统，它可以支持图形显示系统、客户/服务器功能、软件界面和用于维护的控制系统工具箱。

当IS210BPPBH2CAA型号用于TMR(三模冗余)系统时，有三个处理器卡。处理器卡用于在BPPB板和安装在VME机架上的其他板之间执行涡轮机应用软件。

GE IS210BPPBH2CAA 用于蒸汽轮机和燃气轮机原动机

The IS210BPPBH2CAA model is used in the Mark VI turbine control system and is designed as a printed circuit board. One of the main features of the BPPB board used in the Mark VI system is that it can be used in two types of turbine prime movers, namely steam turbines or gas turbines. The main components of the module are eight female plug connectors, which range from two to eighteen pin connectors. Lined up on the left side of the board are six metal oxide rheostat.

When the model is installed in the turbine control system, it will be located in the main control module, and it is also possible to use it with the backup protection module. When in the main control module, there are many software maintenance tools. Maintenance tools vary from protection algorithms to sorting and I/O displays.

The IS210BPPBH2CAA model comes with an operator interface, which is referred to as an HMI or Human Machine interface. The interface is designed for the Microsoft Windows NT PC operating system, which can support graphical display systems, client/server functions, software interfaces, and control system toolkits for maintenance.

When the IS210BPPBH2CAA model is used in TMR(three-mode redundancy) systems, there are three processor cards. The processor card is used to execute the turbine application software between the BPPB board and other boards mounted on the VME rack.
