SR469-P5-HI-A20-E GE 通过扩展TR功能的相位隔离跳闸

SR469-P5-HI-A20-E GE 通过扩展TR功能的相位隔离跳闸

TR跳闸逻辑功能的主要目的是作为单个节点，SR469-P5-HI-A20-E整个终端的所有跳闸都通过该节点进行路由。基本三极跳闸功能的单极和双极扩展的主要目的是满足以下应用：出于系统稳定性的原因，单相故障需要单极跳闸，和/或两相故障需要双极跳闸，例如双回路并联线路。

SR469-P5-HI-A20-E特点

  模块化设计·采用最新PIC芯片，抗干扰能力强·工艺精良，外形美观，性价比高。

常规说明

  安装结构：盘面安装，背后接线

  外壳材料：阻燃塑料

  隔离：电源/输入相互隔离

SR469-P5-HI-A20-E性能指标

  引用标准：GB/T 22264.2-2008

  最大显示：-1999～9999

  显示分辨率：0.001

  最大输入范围：电压：DC 0～600V电流：DC 0～100mA

  输入方式：单端输入

  精度等级：0.5级

  吸收功率：电压：<1.2VA

SR469-P5-HI-A20-E GE 通过扩展TR功能的相位隔离跳闸

The primary purpose of the TR trip logic function is to act as a single node through which all trips of the entire SR469-P5-HI-A20-E terminal are routed. The main purpose of unipolar and bipolar extensions of the basic tripole trip function is to meet the following applications: single-phase faults require unipolar trips for system stability reasons, and/or two-phase faults require bipolar trips, such as double-circuit parallel lines.

SR469-P5-HI-A20-E Features

Modular design · Use the latest PIC chip, strong anti-interference ability · sophisticated technology, beautiful appearance, cost-effective.

General specification

Installation structure: disk installation, rear wiring

Housing material: flame retardant plastic

Isolation: The power supply/input is isolated from each other

SR469-P5-HI-A20-E Performance specifications

Reference standard: GB/T 22264.2-2008

The maximum value is -1999 to 9999

Display resolution: 0.001

Maximum input range: Voltage: DC 0 ~ 600V Current: DC 0 ~ 100mA

Input mode: Single-end input

Accuracy level: 0.5

Absorbed power: Voltage: <1.2VA
