IS220PAICH2A是通用电气公司开发的模拟I/O模块。它是Mark VIe Speedtronic控制系统的一部分。这个I/O包直接连接到终端板上。I/O包通过一个DC-37引脚连接器连接到单工端子板。如果只安装了一个I/O包，支持tmr的终端板有三个DC-37引脚连接器，可以在单工模式下使用。所有这些连接都由I/O包直接支持。

 PAIC (Analog I/O pack)是一个电接口，用于连接一个或两个I/O以太网网络到模拟输入终端板。PAIC包括一个BPPx处理器板以及一个专用于模拟I/O功能的采集板。

该模块有十个模拟输入。前8路输入可设置为5v或10v或4- 20ma电流回路输入。最后两个输入可以设置为1 mA或4-20 mA电流输入。

电流回路输入的负载端子电阻位于端子板上，PAIC通过这些电阻感应电压。PAICH2有两个电流回路输出范围从0到20 mA。它还包括额外的硬件，允许0-200 mA电流仅在第一个输出。

I/O包通过双RJ-45以太网连接器接收和发送数据到控制器，并由一个三针连接器供电。现场设备通过直接连接到相关终端板的DC-37引脚连接器进行通信。LED指示灯提供视觉诊断。

通用GE IS220PAICH2A 模拟输入/输出200毫安

IS220PAICH2A is an analog I/O module developed by General Electric. It is part of the Mark VIe Speedtronic control system. This I/O packet is connected directly to the terminal board. The I/O packet is connected to the simplex terminal board via a DC-37 pin connector. If only one I/O package is installed, the TMR-enabled terminal board has three DC-37 pin connectors that can be used in simplex mode. All of these connections are directly supported by I/O packages.

The PAIC (Analog I/O pack) is an electrical interface for connecting one or two I/O Ethernet networks to an analog input terminal board. The PAIC includes a BPPx processor board and a capture board dedicated to analog I/O functions.

The module has ten analog inputs. The first 8 inputs can be set to 5v or 10v or 4-20ma current loop inputs. The last two inputs can be set to 1 mA or 4-20 mA current inputs.

The current loop input load terminal resistors are located on the terminal board, and the PAIC senses voltage through these resistors. PAICH2 has two current loops with outputs ranging from 0 to 20 mA. It also includes additional hardware that allows 0-200 mA current only at the first output.

I/O packets receive and send data to the controller via dual RJ-45 Ethernet connectors and are powered by a three-pin connector. Field devices communicate via a DC-37 pin connector connected directly to the associated terminal board. LED indicators provide visual diagnosis.
