DS200DCFBG1BJB 是通用电气制造的板组件，是 Mark V Speedtronic 系统的一部分。  DS200DCFBG1BJB 用于为驱动器和机箱风扇提供控制级电源。   DS200DCFBG1BJB 用于 EX2000 应用以及 DC2000、FC2000、GF2000、ME2000、CB2000 和 AC2000 IGBT 驱动应用。

DS200DCFBG1BJB 是一块大型矩形电路板，其表面安装有大量元件。其中包括七个 4 位 DIP 开关设备和十二个可配置跳线。  六个 DIP 开关一起位于电路板的一侧。这些用于缩放或更改许多不同的输入。例如，4 号开关 (SW4) 用于缩放施加到 VCO 输出桥电路的电压。该板还有一个霓虹灯，用于指示 115 VAC 线路中的保险丝熔断，以及两个 LED 指示灯，用于指示 +24 VDC 线路和 -24 VDC 线路中的保险丝熔断。

DS200DCFBG1BJB GE 热电偶

The DS200DCFBG1BJB is a board assembly manufactured by General Electric as part of the Mark V Speedtronic system. The DS200DCFBG1BJB is used to provide control level power to the driver and chassis fans. The DS200DCFBG1BJB is used in EX2000 applications and DC2000, FC2000, GF2000, ME2000, CB2000 and AC2000 IGBT driver applications.

The DS200DCFBG1BJB is a large rectangular circuit board with a large number of components mounted on its surface. These include seven 4-bit DIP switchgear and twelve configurable jumpers. Six DIP switches are located together on one side of the board. These are used to scale or change many different inputs. For example, the No. 4 switch (SW4) is used to scale the voltage applied to the VCO output bridge circuit. The board also has a neon sign to indicate a blown fuse in a 115 VAC line, and two LED indicators to indicate a blown fuse in a +24 VDC line and a -24 VDC line.
