GE 531X122PCNAHG1 电源连接板 是多个原始设备

产品描述

GE电源连接板531X122PCNAHG1是多个原始设备电源连接板的更新部件。 有时需要将 531X122PCNAHG1 板上的组件从一个版本的板拆卸、更换或重新定位到下一个版本。如果您发现更换板上缺少跳线或连接器或其他组件，请参阅板随附的信息以获取说明。在发布之前，对电路板进行了全面测试，并评估了所有差异，并仔细分析了解决方法。

531X122PCNAHG1 板上只有两个跳线用于配置目的，但要使用该板，必须设置跳线。跳线将电路板配置为输出驱动器所需的电压范围。在 531X122PCNAHG1 主板手册中找到您的驱动器型号，其中列出了驱动器的跳线设置。每个跳线有 7 个引脚，当您将跳线插入右侧引脚时，它会定义驱动器的电压。

更改跳线位置的过程很简单，但需要您遵循一些准则。当电路板交付给您时，它被包装在一个保护袋中，以防止静电积聚。将电路板放在袋子里，最好在安装之前将其留在盒子中。拉出板子，将袋子放在干净的表面上，如工作台或桌子。用手或钳子将跳线从出厂设置中移除。小心地将跳线插入驱动器的引脚中。

GE 531X122PCNAHG1 电源连接板 是多个原始设备

Product description

The GE power connector 531X122PCNAHG1 is an updated part of multiple original device power connectors. Sometimes components on the 531X122PCNAHG1 board need to be removed, replaced, or repositioned from one version of the board to the next. If you find that jumpers or connectors or other components are missing from the replacement board, refer to the information that came with the board for instructions. Prior to release, the board was thoroughly tested and all differences were assessed, and the solution was carefully analyzed.

There are only two jumpers on the 531X122PCNAHG1 board for configuration purposes, but to use the board, the jumpers must be set. The jumper configures the board to the required voltage range for the output driver. Find your drive model in the 531X122PCNAHG1 motherboard manual, which lists the jumper Settings for the drive. Each jumper has 7 pins, and when you insert the jumper into the right pin, it defines the voltage of the drive.

The process of changing the position of the jumper is simple, but requires you to follow some guidelines. When the board is delivered to you, it is packaged in a protective bag to prevent static buildup. Place the circuit board in a bag, preferably leaving it in the box before installation. Pull out the board and place the bag on a clean surface, such as a workbench or table. Use your hand or pliers to remove the jumper from factory Settings. Carefully insert the jumper into the pin of the drive.
