产品描述

531X146BDHAFG1--基础驱动卡

531X146BDHAFG1 是通用电气制造的电路板组件，用于其通用驱动系统。 这包括 DC-300 和 AC-300 等驱动器。并非所有 531x 系列主板都与所有系统兼容;请查阅您的手册。

531X146BDHAFG1 用作基础驱动程序。 该卡在角落和边缘钻孔，以便安装。它在电路板表面上切有几个狭缝，这些狭缝通常由一个或多个组件横向。该板标有 002/0、VA-4、FR00/0、005/0 和 004/0 等代码。它的表面还印有三个图表，提供有关跳线设置及其对电路板功能的影响的信息。

531X146BDHAFG1 的中心附近有一个变压器。该组件使用彩色（红色、蓝色、白色）线连接到多个端子引脚。该板有 <> 个散热器、<> 个垂直排针连接器、<> 个垂直排针电缆连接器、超过 <> 个晶体管和多个电阻网络阵列。它有多个跳线开关;大多数跳线被标记为“X”或“Y”。该板具有各种电阻器、二极管和电容器。有关更多信息，请参阅电路板数据表。

GE 531X146BDHAFG 燃机系统燃机卡

Product description

531X146BDHAFG1: Base driver card

The 531X146BDHAFG1 is a circuit board component manufactured by General Electric for its universal drive system. This includes drives such as the DC-300 and AC-300. Not all 531x series motherboards are compatible with all systems; Please refer to your manual.

531X146BDHAFG1 is used as the base driver. The card is drilled in the corners and edges for easy installation. It has several slits cut into the board surface, which are usually transverse by one or more components. The board is marked with codes such as 002/0, VA-4, FR00/0, 005/0, and 004/0. It also has three diagrams printed on its surface that provide information about jumper Settings and their impact on the board's functionality.

There is a transformer near the center of the 531X146BDHAFG1. The component is connected to multiple terminal pins using colored (red, blue, white) wires. The board has <> heat sinks, <> vertical pin connectors, <> vertical pin cable connectors, more than <> transistors, and multiple resistance network arrays. It has multiple jumper switches; Most jumpers are labeled "X" or "Y". The board has various resistors, diodes and capacitors. See the board data sheet for more information.
