GE 531X170TBSACG1  是一款窄而长的矩形板

GE 531X170TBSACG1  是一款窄而长的矩形板

产品描述

531X170TBSACG1 是通用电气制造的 TB 选件卡。 该 PCB 并非设计为特定驱动系统的组件;相反，它用于GE创建的各种通用驱动系统，包括DC-300驱动器。请查看您的用户指南以确定兼容性。

531X170TBSACG1 是一款窄而长的矩形板。它的尺寸为 11 x 2.75 英寸，并标有 F31X170TBSACG1、004/0 和 FR00/0 等代码。该板具有工厂制造的孔，以允许安装选项。这包括每个角上都有一个安装孔，一个在电路板的中心，两个在长板边缘。该板有两个端子排，其中一个具有 <> 个螺钉连接，另一个具有 <> 个螺钉连接。这些连接都在电路板表面进行了编号和标记。

531X170TBSACG1 由几个其他组件组成。这包括三个接头连接器（一个 9 针、一个 16 针和一个 24 针）、一个公针电缆连接器和一个母头电缆连接器。该板具有一个刺接连接器、一个聚酯-乙烯基电容器、一个跳线开关和一个硅桥整流二极管。该板具有一个电感线圈、一个继电器和两个开关元件。该继电器是 DS2E-M-DC24V 2 C 型继电器，标称工作功率为 400 mW。每个开关组件都有四个拨动开关，可设置为“DCE”或“DTE”。

GE 531X170TBSACG1  是一款窄而长的矩形板

Product description

The 531X170TBSACG1 is a TB option card manufactured by General Electric. The PCB is not designed as a component of a specific drive system; Instead, it is used in a variety of general-purpose drive systems created by GE, including DC-300 drives. Check your user guide to determine compatibility.

The 531X170TBSACG1 is a narrow and long rectangular board. It measures 11 x 2.75 inches and is marked with codes such as F31X170TBSACG1, 004/0 and FR00/0. The board has factory-made holes to allow mounting options. This includes a mounting hole at each corner, one in the center of the board and two at the edge of the longboard. The board has two terminal blocks, one having a <> screw connection and the other having a <> screw connection. These connections are numbered and marked on the board surface.

The 531X170TBSACG1 consists of several other components. This includes three joint connectors (a 9-pin, a 16-pin, and a 24-pin), a male cable connector, and a female cable connector. The board has a splice connector, a polyester-vinyl capacitor, a jumper switch, and a silicon bridge rectifier diode. The board has an inductor coil, a relay and two switching elements. The relay is a DS2E-M-DC24V2C type relay with a nominal operating power of 400 mW. Each switch assembly has four toggle switches that can be set to "DCE" or "DTE".

GE 531X170TBSACG1  是一款窄而长的矩形板

立即询盘

1.所有产品图片均为实物图，如需更多图片请联系我们。

2.所有售出产品质量保证一年，如果您在一个月内收到货物

我们可以给您更换或退回任何质量问题。

3.我们是中国大的工控产品供应商，如果您需要其他类型的产品，

请向我们询问，我们会立即给您答 ^K zmx
