531X171TMAABG1 GE 端子板继电器卡

531X171TMAABG1 GE 端子板继电器卡

产品描述

GE端子板继电器卡531X171TMAABG1包含接口电路和用于大多数信号I/O的连接端子。该板通过电缆连接到驱动器控制板。GE 端子板继电器卡 531X171TMAABG1 具有 RS232C 串行端口连接，可用于将板连接到笔记本电脑或其他设备。

要使用连接，您必须确保笔记本电脑上的每个端口都分配了一个唯一的地址。要配置串行端口，请访问设置配置实用程序并分配地址，并确保端口未被禁用。您还可以确保设备兼容。您还可以确保串行连接器连接到笔记本电脑上的正确连接器。串行连接可用作驱动器配置工具和诊断工具的接口。

该板包含跳线和 DIP 开关，使安装人员能够配置板以在驱动器中使用。在安装更换板之前，请仔细找到有缺陷的板上的跳线和 DIP 开关，并将跳线和 DIP 开关设置在更换板上以匹配有缺陷的板。您可能会发现跳线和开关的位置已在新板上更新。即使位置可能已更改，也要在新板上找到跳线标识符，并将跳线设置在相同的位置。

531X171TMAABG1 GE 端子板继电器卡

Product description

GE terminal board relay card 531X171TMAABG1 contains the interface circuit and connection terminals for most signal I/O. The board is connected to the driver control board by cable. GE terminal board relay card 531X171TMAABG1 has RS232C serial port connection and can be used to connect the board to a laptop or other device.

To use a connection, you must make sure that each port on your laptop is assigned a unique address. To configure a serial port, access the Setup Configuration utility and assign an address, and make sure the port is not disabled. You can also ensure that your devices are compatible. You can also make sure that the serial connector is connected to the correct connector on your laptop. The serial connection can be used as an interface for drive configuration tools and diagnostic tools.

The board contains jumpers and DIP switches that enable installers to configure the board for use in the drive. Before installing the replacement board, carefully locate the jumper and DIP switch on the defective board and set the jumper and DIP switch on the replacement board to match the defective board. You may find that the position of the jumper and switch has been updated on the new board. Even though the location may have changed, find the jumper identifier on the new board and set the jumper to the same location.

531X171TMAABG1 GE 端子板继电器卡

立即询盘

1.所有产品图片均为实物图，如需更多图片请联系我们。

2.所有售出产品质量保证一年，如果您在一个月内收到货物

我们可以给您更换或退回任何质量问题。

3.我们是中国大的工控产品供应商，如果您需要其他类型的产品，

请向我们询问，我们会立即给您答 ^K zmx
