GE 531X171TMAAEG2 端子板继电器卡 具有多个连接器

GE 531X171TMAAEG2 端子板继电器卡 具有多个连接器

产品描述

GE端子板继电器卡531X171TMAAEG2包含接口电路和连接端子，用于大多数信号I/O。该板通过电缆连接到驱动器控制板。

GE端子板继电器卡531X171TMAAEG2具有多个连接器，用于将电路板连接到驱动器中的组件的电缆。在开始更换之前，请检查有缺陷的电路板并注意与其连接的所有电线和电缆。该板具有一个端子，该端子上连接了多根单线，提供发送到驱动器中其他组件的电信号。它还提供发送到电路板进行处理的信号。创建标签，提供有关端子上电线连接位置的信息。这将避免更换板接线不正确的可能性，这会导致驱动器的停机时间进一步增加。

要从端子上取下电线，请创建标签并将其贴在电线上。每个端子都有一个单独的连接器，用螺钉固定到位。使用螺丝刀松开将电线固定到位的螺钉。从端子上拔下电线，并将其移到一侧，同时将新板安装在驱动器中。要将电线安装到新板中，请使用螺丝刀松开螺丝并将电线插入连接器中。确保裸机在连接器中。用螺丝刀拧紧连接器。

GE 531X171TMAAEG2 端子板继电器卡 具有多个连接器

Product description

GE Terminal board Relay Card 531X171TMAAEG2 contains interface circuits and connection terminals for most signal I/O. The board is connected to the driver control board by cable.

GE Terminal board Relay Card 531X171TMAAEG2 has multiple connectors for connecting the circuit board to the cables of the components in the driver. Before starting the replacement, check the defective circuit board and note all wires and cables connected to it. The board has a terminal on which multiple single wires are connected to provide electrical signals sent to other components in the driver. It also provides a signal that is sent to the board for processing. Create labels that provide information about where the wires are connected on the terminals. This will avoid the possibility of incorrect wiring of the replacement board, which could lead to further increased downtime of the drive.

To remove the wire from the terminal, create a label and attach it to the wire. Each terminal has a separate connector that is secured in place with screws. Use a screwdriver to loosen the screws holding the wires in place. Unplug the wire from the terminal and move it to the side while installing the new board in the driver. To install the wire into the new board, use a screwdriver to loosen the screws and insert the wire into the connector. Make sure the bare device is in the connector. Tighten the connector with a screwdriver.

GE 531X171TMAAEG2 端子板继电器卡 具有多个连接器

立即询盘

1.所有产品图片均为实物图，如需更多图片请联系我们。

2.所有售出产品质量保证一年，如果您在一个月内收到货物

我们可以给您更换或退回任何质量问题。

3.我们是中国大的工控产品供应商，如果您需要其他类型的产品，

请向我们询问，我们会立即给您答 ^K zmx
