通用电气 531X187VCTABG1 是一款电压电流传感器卡。 这款双通道板专为 531X 系列驱动板开发。它被设计用于在驱动器产品操作可调驱动器中运行，包括 AC-300、DC-300 和 AC-500 系列驱动器。驱动器产品操作系列的其他成员可以在安装此卡的情况下运行。安装后，电路板上的传感器既可以用作电压到隔离电流，也可以用作电压到隔离电压。

安装后，531X187VCTABG1 为输入电压到隔离电流提供转换点。 可以在卡上找到两个标记为 ATB 和 BTB 的隔离输出。该板接收 24 VDC 电源，该电源产生隔离式双电源，馈送到两个通道的输出。电路板上的许多功能可以进行调整，以满足工作的特定要求。卡上的可配置跳线允许用户调整滤波时间常数。用户还可以使用板载开关调整产生满量程输出所需的输入电平。

用户应努力满足设备制造商概述的所有安装参数。只有经过处理和组装驱动板培训的合格人员才能安装此板。接线是另一个关键方面，只能由有经验的人员执行。要查看 531X187VCTABG1 接线和安装的完整指南，请参阅该板的手册和数据表。 通用电气是 531X 系列主板的最初技术支持提供商。

GE 531X187VCTABG1  是一款电压电流传感器卡

Product description

The General Electric 531X187VCTABG1 is a voltage and current sensor card. This dual channel board was developed specifically for the 531X series drive board. It is designed to operate in drive product operation tunable drives, including the AC-300, DC-300 and AC-500 series drives. Other members of the Drive product operation family can run with this card installed. Once installed, the sensor on the board can be used as either a voltage to isolation current or a voltage to isolation voltage.

After installation, the 531X187VCTABG1 provides a transition point for the input voltage to the isolated current. Two isolated outputs labeled ATB and BTB can be found on the card. The board receives a 24 VDC power supply, which produces isolated dual power supplies that feed output to two channels. Many of the functions on the board can be adjusted to meet the specific requirements of the job. A configurable jumper on the card allows the user to adjust the filtering time constant. The user can also adjust the input level required to produce a full-scale output using an onboard switch.

The user should strive to meet all installation parameters outlined by the device manufacturer. Only qualified personnel trained in handling and assembling drive boards can install this board. Wiring is another key aspect that can only be performed by experienced personnel. For a complete guide to wiring and installation of the 531X187VCTABG1, refer to the board's manual and data sheet. Ge was the initial technical support provider for the 531X series motherboard.
