产品描述

通用电气开发了 531X191RTBAHG1 板作为继电器端子板。它是为 531X 系列替换板制造的。GE品牌的许多驱动器和励磁器都可以将此卡安装在其机柜中。安装后，该卡为驱动器提供七个额外的继电器，可用于控制外部电路。它还允许用户使用卡的端子板访问触点和线圈。

该继电器端子板的内容包括继电器及其相关电路。继电器的线圈额定电压为 115 VAC，频率为 50/60 Hz。将这些速率的电流保持在 9 mA。531X191RTBAHG1 上的每个触点都具有 0.7 安培直流或 105 VDC 的电压。 其他功能包括该器件能够将继电器触点和 RTB 点制成表格。每个继电器都有指示灯 LED。当设备上的线圈通电时，继电器将亮起，以视觉方式将其传达给用户。该板还可用于控制输入的外部电路。

用户应满足有关设备安装的任何参数。 驱动功能取决于这些要求，因为它们降低了设备损坏的风险。531X191RTBAHG1 只能由经过培训处理驱动板的合格人员安装。正确的接线是电路板和设备性能不可或缺的一部分。 安装前，请参阅相应的设备手册和数据表以获取完整的接线指南。该继电器板的技术支持最初由设备制造商通用电气提供。

GE 531X191RTBAHG1 作为继电器端子板

Product description

Ge developed the 531X191RTBAHG1 board as the relay terminal board. It is manufactured for the 531X series replacement board. Many GE branded drives and exciters can have the card installed in their cabinets. Once installed, the card provides the driver with seven additional relays that can be used to control external circuits. It also allows the user to access contacts and coils using the card's terminal plate.

The content of the relay terminal board comprises the relay and its related circuit. The coil of the relay is rated at 115 VAC and the frequency is 50/60 Hz. Keep the current at these rates at 9 mA. Each contact on the 531X191RTBAHG1 has a voltage of 0.7 amps DC or 105 VDC. Additional features include the device's ability to tabulate relay contacts and RTB points. Each relay has an indicator LED. When the coil on the device is energized, the relay lights up to visually communicate it to the user. The board can also be used to control the external circuit of the input.

The user shall meet any parameters regarding the installation of the equipment. The drive function depends on these requirements as they reduce the risk of damage to the equipment. The 531X191RTBAHG1 can only be installed by qualified personnel trained to handle driver boards. Proper wiring is an integral part of board and device performance. Before installation, refer to the appropriate equipment manual and data sheet for complete wiring guidelines. Technical support for the relay board was initially provided by equipment manufacturer General Electric.
