产品描述

531X191RTBALG3 卡由通用电气制造，用作继电器端子板。 作为 GE 531X 替换驱动板系列的成员，该卡可安装到整个品牌的多个驱动器和激励器中。该板为其已安装的主机驱动器提供了两个功能。安装此板后，驱动器有七个继电器位置可用。该卡还允许用户访问船上的线圈和触点。

继电器端子板的功能提供给主机驱动器。安装后，端子卡提供七个继电器位置，用于外部连接。任何连接的电路都可以使用 531X191RTBALG3 板进行控制。 RTB 点和继电器触点的表格可以通过卡计算。该卡是该板的 G3 版本，提供与其他版本不同的特定电压和电流速率。 每个继电器内的线圈额定值为 115 VAC，而触点的额定值为 125 VAC 或 28 VDC。触点的额定电流为 2.4 A，电路板浪涌电流为 25 mA，保持电流为 14 mA。

在开始安装此主板之前，请务必查看所有提供的安装参数。为保护电路板的敏感组件，仅允许经过培训的人员处理和安装 531X191RTBALG3 卡。在开始设备安装之前，应彻底查看所有接线说明。 相应的设备手册和数据表包含全面的接线和安装指南。该设备的制造商通用电气是该继电器端子板的原始技术支持提供商。

GE 531X191RTBALG3 用作继电器端子板

Product description

The 531X191RTBALG3 card was manufactured by General Electric as a relay terminal board. As a member of the GE 531X replacement driver board family, the card can be installed into multiple drives and exciters across the brand. The board provides two functions for its installed host drive. After installing this board, the driver has seven relay positions available. The card also allows users to access coils and contacts on board.

The function of the relay terminal board is provided to the host driver. Once installed, the terminal card provides seven relay positions for external connections. Any connected circuit can be controlled using the 531X191RTBALG3 board. The table of RTB points and relay contacts can be calculated by card. The card is a G3 version of the board that offers specific voltage and current rates that differ from other versions. The coils within each relay are rated 115 VAC, while the contacts are rated 125 VAC or 28 VDC. The rated current of the contact is 2.4 A, the board surge current is 25 mA, and the holding current is 14 mA.

Before you begin installing this motherboard, be sure to review all provided installation parameters. To protect sensitive components of the board, only trained personnel are allowed to handle and install 531X191RTBALG3 cards. Thoroughly review all wiring instructions before starting equipment installation. The corresponding equipment manuals and data sheets contain comprehensive wiring and installation guides. General Electric, the manufacturer of the device, is the original technical support provider for the relay terminal board.
