产品描述

531X207LCSAEG1 是为通用电气的 531X 系列替换板开发的局域网 （LAN） 电流源板。作为替代板，该卡可用于一系列 GE 品牌的驱动器和励磁器。当安装在驱动器中时，此电流源板为驱动器的 LAN 提供额定电压为 5 VDC 和 15 VDC 的电源，以及 0.3 A 的电压限制电流源。该卡的所有电源均来自 115 VAC 保险丝保护输入电源。

驱动器的 LAN 操作取决于此主板的正常运行。531X207LCSAEG1 包括许多可配置选项，允许用户将此板应用于许多任务。电路板上唯一标有 JP1 的跳线使用户能够在 5 VDC 和 15 VDC 电源之间进行选择。位置 1.2 允许 5 VDC 电源，而位置 2.3 提供 15 VDC 电源。这些产生的输出电压也可以使用一个集成电位器进行配置。连接到卡上的12点端子用作接口点，发送和接收电压信号。

应满足电路板随附的任何安装参数。遵循制造商提供的所有准则将确保 531X207LCSAEG1 板以及整个驱动系统的完整性。仅允许在处理驱动器组件方面接受过培训的合格人员处理或安装此板。

GE 531X207LCSAEG1 替换板开发的局域网 （LAN） 电流源板

Product description

The 531X207LCSAEG1 is a local area network (LAN) current source board developed for General Electric's 531X series replacement board. As an alternative board, the card can be used in a range of GE branded drives and exciters. When installed in the driver, this current source board provides the driver's LAN with rated voltages of 5 VDC and 15 VDC, as well as A voltage limited current source of 0.3 A. All power to the card comes from the 115 VAC fuse protection input power supply.

The LAN operation of the drive depends on the proper operation of this motherboard. The 531X207LCSAEG1 includes a number of configurable options that allow users to apply this board to many tasks. The only jumper on the board labeled JP1 allows users to choose between a 5 VDC and a 15 VDC power supply. Position 1.2 allows 5 VDC power, while position 2.3 provides 15 VDC power. These generated output voltages can also be configured using an integrated potentiometer. The 12-point terminals connected to the card serve as interface points, sending and receiving voltage signals.

Any mounting parameters included with the board should be met. Compliance with all guidelines provided by the manufacturer will ensure the integrity of the 531X207LCSAEG1 board as well as the entire drive system. Only qualified personnel trained in handling driver components are allowed to handle or install this board.
