GE 531X207LCSAFG1 是一款局域网（LAN）电流源板

GE 531X207LCSAFG1 是一款局域网（LAN）电流源板

产品描述

531X207LCSAFG1是一款局域网（LAN）电流源板。 该装置由通用电气为其 531X 系列电路板开发。该卡可以被各种GE驱动器和励磁器接受。安装后，该卡为驱动器的 LAN 系统提供额定电压为 5 VDC 或 15 VDC 的电源。该板还提供额定电流为 0.3 A 的限压电流源。一个 115 VDC 保险丝保护输入为电路板提供源电源。

系统灵活性是 531X207LCSAFG1 的主要设计特点。用户可以根据个人负载要求在两个LAN电源之间进行选择。要在电源之间进行选择，将电路板的跳线移动到位置 1.2 可提供 5 VDC，而 2.3 可提供 15 VDC。用户还可以选择电路板创建的电压输出，以调整到所选的输入。输出电压可通过板上电位计进行选择。所有发送到卡和从卡发送的信号都通过集成在卡中的 12 点终端进行中继。

设备保存取决于用户是否遵循电路板提供的所有大纲安装参数。遵守这些准则将使驱动功能受益。531X207LCSAFG1 的安装只能由经过培训的合格人员来处理这些敏感板。有关接线和安装电路板的完整指南，请参阅设备手册及其数据表。

GE 531X207LCSAFG1 是一款局域网（LAN）电流源板

Product description

The 531X207LCSAFG1 is a local area Network (LAN) current source board. The device was developed by General Electric for its 531X series circuit board. The card can be accepted by a variety of GE drives and exciters. When installed, the card provides power to the driver's LAN system with a rated voltage of 5 VDC or 15 VDC. The board also provides A voltage limiting current source with a rated current of 0.3 A. A 115 VDC fuse protection input provides source power to the board.

System flexibility is the main design feature of the 531X207LCSAFG1. Users can choose between two LAN power supplies based on their personal load requirements. To choose between power supplies, moving the jumper of the board to position 1.2 provides 5 VDC, while 2.3 provides 15 VDC. The user can also select the voltage output created by the board to adjust to the selected input. The output voltage can be selected by an on-board potentiometer. All signals sent to and from the card are relayed through a 12-point terminal integrated into the card.

Device preservation depends on whether the user follows all outline installation parameters provided by the board. Adherence to these guidelines will benefit the driver function. Installation of the 531X207LCSAFG1 should only be done by qualified personnel trained to handle these sensitive panels. For complete guidance on wiring and mounting boards, refer to the device manual and its data sheet.
