GE 531X211KLDABG1 用作按键/LED/显示板

531X211KLDABG1 是 GE 制造的电路板组件，适用于该公司发布的几种不同的驱动系统。 其中许多驱动器现在已经过时，但它们最初由GE设计为能够用于工业应用的动态、灵活的系统。

531X211KLDABG1 用作按键/LED/显示板。该板由七个字母数字显示器组成。这些显示器使用两颗螺钉将螺钉安装到电路板上。这些组件中的每一个都有一个十位数的显示屏。它们在电路板上以两行三台显示器和一台显示器的形式排列。

531X211KLDABG1 在电路板的右下象限有一个 LED 指示灯区域。该字段由 <> 个红色 LED 指示灯组成，分为 <> 行，每行 <> 个。

531X211KLDABG1 板上的其他组件包括 <> 个电阻网络阵列、一个垂直公头电缆连接器、<> 个跳线开关、<> 个晶体管和 <> 个集成电路。该板具有二极管、电容器和电阻器。电阻器通常由金属膜制成。电容器是电解电容器和陶瓷电容器。

531X211KLDABG1 沿两个边缘标记，带有对齐标记（字母、数字）。该板的表面上有多个代码，包括以 F31X 开头的辅助板号。该板沿边缘和角落钻孔。大多数组件都标有参考指示符。此板和其他 531x 板的技术支持由通用电气提供。印刷版技术支持仍可通过 GE 出版物（如手册、用户指南和数据表）获得。

GE 531X211KLDABG1 用作按键/LED/显示板

The 531X211KLDABG1 is a GE manufactured circuit board component that works with several different drive systems released by the company. Many of these drives are now obsolete, but they were originally designed by GE as dynamic, flexible systems capable of being used in industrial applications.

531X211KLDABG1 is used as a button /LED/ display board. The board consists of seven alphanumeric displays. These displays use two screws to attach the screws to the circuit board. Each of these components has a ten-digit display. They are arranged on the circuit board in two rows of three monitors and one monitor.

The 531X211KLDABG1 has an LED indicator area in the lower right quadrant of the board. The field consists of <> red LED indicators, divided into <> rows, each row <>.

Other components on the 531X211KLDABG1 board include <> a resistance network array, a vertical male cable connector, <> a jumper switch, <> a transistor, and <> an integrated circuit. The plate has a diode, capacitor and resistor. Resistors are usually made of metal film. Capacitors are electrolytic capacitors and ceramic capacitors.

531X211KLDABG1 marks along two edges, with alignment marks (letters, numbers). There are multiple codes on the surface of the board, including the auxiliary board number beginning with F31X. The plate is drilled along the edges and corners. Most components are labeled with reference indicators. Technical support for this board and other 531x boards is provided by General Electric. Print technical support is still available through GE publications such as manuals, user guides, and data sheets.
