产品描述

531X300CCHAHM3 是通用电气公司制造的控制 PCB（印刷电路板），用于其通用驱动系统，如 DC-300 驱动器。 这些驱动器是专为工业应用而设计的灵活而强大的驱动系统。您的用户指南或系统手册将有助于确定 531x 主板是否与您的驱动器兼容。

531X300CCHAHM3 是一款矩形板，每个角都有一个工厂钻孔的安装点。该板在沿板边缘的点处有额外的工厂钻孔。 它标有 VA-4、CT 88-12、FR00/0 和 F31X300CCHAFG1 等代码。

531X300CCHAHM3 有六个 LED 指示灯。 LED 位于电路板左上角的一条直线上。它们被标记为 1、2、4、8、16 和 32。靠近这些元件的是该板的 <> 个电阻网络阵列中的 <> 个。该板还具有 <> 个电位计和 <> 个稳压器。

531X300CCHAHM3 有一个开关组件。它有两个接头连接器和六个公垂直针电缆连接器。其中一些电缆连接器用于与辅助板（如果已安装）进行通信。在电路板表面插入了八个支架，以支撑这些可选的辅助板。

531X300CCHAHM3 使用不同电阻的金属膜电阻器。它有电解和聚酯乙烯基电容器，但板上的大多数电容器都是由陶瓷材料制成的。该板具有单个电感器组件，还装有 TP 测试点、跳线开关和集成电路。

GE 531X300CCHAHM3 数字量扩展模块

Product description

The 531X300CCHAHM3 is a control PCB (printed circuit board) manufactured by General Electric for use in its general-purpose drive systems, such as DC-300 drivers. These drives are flexible and powerful drive systems designed for industrial applications. Your user guide or system manual will help determine if the 531x motherboard is compatible with your drive.

The 531X300CCHAHM3 is a rectangular plate with a factory-drilled mounting point at each corner. The board has additional factory holes at points along the edge of the board. It is marked with codes such as VA-4, CT 88-12, FR00/0, and F31X300CCHAFG1.

The 531X300CCHAHM3 has six LED indicators. The LED is located on a straight line in the top left corner of the board. They are labeled 1, 2, 4, 8, 16, and 32. Adjacent to these elements are <> of the <> resistor network array of the board. The board also has <> a potentiometer and <> a voltage regulator.

The 531X300CCHAHM3 has a switch assembly. It has two splice connectors and six male vertical pin cable connectors. Some of these cable connectors are used to communicate with the auxiliary board (if installed). Eight stands are inserted into the board surface to support these optional auxiliary boards.

531X300CCHAHM3 uses metal film resistors with different resistors. It has electrolytic and polyester vinyl capacitors, but most of the capacitors on the board are made of ceramic materials. The board has a single inductor assembly and also houses a TP test point, jumper switch and integrated circuit.
