产品描述

531X300CCHAWM3 是通用电气生产的电路板，作为其多个工业通用驱动系统（包括 DC-300 驱动器）中使用的组件。

531X300CCHAWM3 是一款系统控制卡。它在每个角上都经过工厂钻孔，并沿每个边缘钻孔一次，以便安装。 该板带有 VA-4、003/0、004/0、002/0 和 FR00/0 等代码。它还带有上述板号和备用编号 （F31X300CCHAFG1）。大多数组件都标有制造商 ID 号和电路板参考指示符。

531X300CCHAWM3 具有 <> 个电位计和 <> 多个电阻网络阵列。它使用由金属膜材料制成的电阻器和通常由陶瓷材料制成的电容器制成。但是，板上的电容器有些是由电解材料制成的，有些是聚酯乙烯基。

531X300CCHAWM3 表面的连接器包括 531 个垂直针电缆连接器和 300 个接头连接器。该板还具有多个端子引脚连接器。板面有八个支架;这些设计用于将两个辅助（子）板连接到 3X<>CCHAWM<> 板。

531X300CCHAWM3 上的其他组件包括集成电路、跳线开关、LED、晶体管和表面布线。该板还有一个按钮开关。这是一个复位开关。它位于棋盘的左下角附近。有关安装和处理程序的信息，请参阅原始设备经理的出版物。GE为该板和531x系列的所有板组件提供了原始技术支持。

GE 531X300CCHAWM3 是一款系统控制卡

Product description

The 531X300CCHAWM3 is a circuit board manufactured by General Electric as a component used in several of its industrial general-purpose drive systems, including DC-300 drivers.

The 531X300CCHAWM3 is a system control card. It is drilled through factory holes at each corner and drilled once along each edge for installation. The board comes with codes VA-4, 003/0, 004/0, 002/0, and FR00/0. It also carries the above board number and the alternate number (F31X300CCHAFG1). Most components are labeled with a manufacturer ID number and a board reference indicator.

The 531X300CCHAWM3 has <> potentiometers and <> multiple resistance network arrays. It is made using resistors made of metal film materials and capacitors usually made of ceramic materials. However, some of the capacitors on the board are made of electrolytic materials, and some are polyester vinyl.

The connectors on the 531X300CCHAWM3 surface include 531 vertical pin cable connectors and 300 connector connectors. The board also has multiple terminal pin connectors. There are eight supports on the plate; These are designed to connect two auxiliary (child) boards to 3X<>CCHAWM<> boards.

Other components on the 531X300CCHAWM3 include integrated circuits, jumper switches, leds, transistors, and surface wiring. The board also has a push-button switch. This is a reset switch. It is located near the bottom left corner of the board. For information on installation and processing procedures, see the original Equipment Manager's publications. GE provided original technical support for the board and all board components of the 531x series.
