产品描述

531X305NTBAPG1 卡由通用电气开发，作为 NTB/3TB 终端板。该卡最初是为 531X 系列替换驱动板开发的。该主板系列的成员适合安装到 GE 品牌的多个驱动器中。安装后，此卡提供对驱动器中未找到的许多接口工具的访问。应用包括串行和继电器输出、低电平模拟 I/O、编码器和电源。

安装 NTB/3TB 终端板可提供稳压和非稳压电源。主机驱动器可以从额定电压为 5 VDC 和 15 VDC 的稳压电源或额定电压为 24 VDC 或 120 VAC 的非稳压电源供电。用户可以配置许多电路板设置，以符合特定的负载要求。 5V 和 15V 编码器可以通过电路板上的跳线进行调整。该板还提供 120 个 A 型和 C 型继电器输出的组合。所有集成继电器都包括额定电压为 <> VAC 的触点。该卡还包含四个电位计，允许对低电平模拟 I/O 进行缩放。

在从包装中取出设备之前，请重新view 通用电气提供的安装参数。为确保所有板功能正常运行，请仅允许经过培训的人员操作和安装此板。全面的接线指南可在系列手册和设备数据表中找到。制造商通用电气是该端子板的原始技术支持提供商。

GE 531X305NTBAPG PCB电路板 工控备件

Product description

The 531X305NTBAPG1 card was developed by General Electric as an NTB/3TB terminal board. The card was originally developed for the 531X series replacement driver board. Members of this motherboard family are suitable for installation into multiple drives under the GE brand. After installation, this card provides access to many interface tools not found in the drive. Applications include serial and relay outputs, low-level analog I/O, encoders, and power supplies.

NTB/3TB terminal boards are installed to provide both regulated and unregulated power supplies. The host driver can be powered from a regulated supply rated at 5 VDC and 15 VDC or an unregulated supply rated at 24 VDC or 120 VAC. Users can configure many board Settings to meet specific load requirements. The 5V and 15V encoders can be adjusted via jumpers on the circuit board. The board also offers A combination of 120 Type A and Type C relay outputs. All integrated relays include contacts rated for <> VAC. The card also contains four potentiometers that allow scaling of low-level analog I/O.

Before removing the device from the package, re-view the installation parameters provided by GE. To ensure that all boards function properly, only trained personnel are allowed to operate and install the board. Comprehensive wiring guidelines can be found in series manuals and equipment data sheets. Manufacturer General Electric is the original technical support provider for the terminal board.
