GE 531X307LTBAHG1 6G数字控制 I/O

GE 531X307LTBAHG1 6G数字控制 I/O

产品描述

通用电气开发了 531X307LTBAHG1 局域网 （LAN） 终端板，用于 531X 系列替换板。GE 系列的一系列驱动器和励磁器都可以安装此卡。安装该卡可为驱动器提供用于控制驱动器和各种外部设备的接口系统。按钮、指示灯和联锁装置等物品是可能使用的一些外部设备。

进出驱动器的LAN信号通过接口平台提供，以便相应地进行分配。安装后，531X307LTBAHG1 为驱动器提供 2 个可配置的控制输入插头。输入可接受额定电压在 240 至 24 V 之间，包括交流和直流电源。输入端的电压被转换为控制板可消化的 <>VDC 逻辑信号。现在，信号可以很容易地在整个LAN终端和NTB终端板以及驱动控制板中传输。低电压、低电流 C 型继电器触点连接器包括板上的七个控制输出。

遵循主板和驱动器制造商提供的所有安装参数。 满足这些要求将保护整个驱动系统免受意外损坏。仅允许经过培训的合格人员处理 531X307LTBAHG1 板。有关LAN端子板接线的图解指南，请参阅该板的手册和数据表。通用电气最初为该主板以及整个 531X 系列提供技术支持。

GE 531X307LTBAHG1 6G数字控制 I/O

Product description

Ge has developed the 531X307LTBAHG1 Local Area Network (LAN) terminal board for the 531X Series replacement board. The card can be installed on a range of GE drivers and exciters. Installing the card provides the drive with an interface system for controlling the drive and various external devices. Items such as buttons, indicators, and interlocking devices are some of the external devices that may be used.

LAN signals to and from the driver are provided through the interface platform so that they can be allocated accordingly. Once installed, the 531X307LTBAHG1 provides the driver with 2 configurable control input plugs. Inputs can accept rated voltages between 240 and 24 V, including AC and DC power supplies. The voltage at the input is converted into a <>VDC logic signal that the control board can digest. Now, signals can be easily transmitted across the entire LAN terminal and NTB terminal board, as well as the drive control board. Low voltage, low current Type C relay contact connectors include seven control outputs on the board.

Follow all installation parameters provided by the motherboard and drive manufacturer. Meeting these requirements will protect the entire drive system from accidental damage. Only trained and qualified personnel are allowed to handle 531X307LTBAHG1 boards. For an illustrated guide to LAN terminal board wiring, refer to the board's manual and data sheet. Ge initially provided technical support for the motherboard as well as the entire 531X series.

GE 531X307LTBAHG1 6G数字控制 I/O
