GE 531X309SPCAGG1  信号处理器卡

GE 531X309SPCAGG1  信号处理器卡

产品描述

通用电气开发了 531X309SPCAGG1 作为信号处理器卡。它属于 531X 系列替换板。与该系列的大多数成员一样，该板可以安装到任意数量的GE制造的驱动器和励磁器中。运行时，该板用于处理 LAN 控制板和驱动器控制板接收到的任何 I/O。

531X309SPCAGG1 包含许多有用的功能，可改善整体驱动器功能。编码器和转速计配有与电路板的接口介质。然后，从这些外部机构接收到的电源速度反馈被发送到控制板进行速度调节。该卡将三个电流参考信号和电压电平信号转换为电压参考信号。然后，这些新转换的信号被发送到驱动器的控制板。输入的 RS-422 串行信号由该板处理，然后发送到系统的电机控制处理器。用户可以使用板载开关、跳线和电位器配置电路板的硬件配置、信号滤波器和其他选项。

应遵循主板制造商概述的安装参数。遵循所有提供的准则将保持驱动器的完整性。请勿让任何未经培训的人员处理或安装电路板。有关 531X309SPCAGG1 板接线的完整指南，请参阅处理器卡的手册和数据表。技术支持最初由制造商通用电气提供。

GE 531X309SPCAGG1  信号处理器卡

Product description

General Electric developed the 531X309SPCAGG1 as a signal processor card. It belongs to the 531X series replacement board. Like most members of the family, the board can be installed into any number of GE manufactured drives and exciters. At run time, the board is used to process any I/O received by the LAN control board and the drive control board.

The 531X309SPCAGG1 contains many useful features that improve overall drive functionality. Encoders and tachometers are provided with interface media to the circuit board. The power speed feedback received from these external mechanisms is then sent to the control board for speed adjustment. The card converts three current reference signals and voltage level signals into voltage reference signals. These newly converted signals are then sent to the drive's control board. The input RS-422 serial signal is processed by the board and then sent to the system's motor control processor. Users can configure the board's hardware configuration, signal filters, and other options using onboard switches, jumpers, and potentiometers.

The installation parameters outlined by the motherboard manufacturer should be followed. Following all provided guidelines will maintain the integrity of the drive. Do not allow any untrained personnel to handle or install the circuit board. For a complete guide to wiring the 531X309SPCAGG1 board, see the processor card's manual and data sheet. Technical support was initially provided by manufacturer General Electric.
