产品描述

GE点火电路控制板DS200FCRRG1AKD具有1个接线端子，带有用于95根信号线的端子。它还包含 10 个 2 针连接器、2 根带状电缆和一个可编程逻辑器件。10 个 2 针连接器的 ID 以数值开头，以 PL 结尾。这些编号按顺序分配并打印在电路板表面，以便安装人员或服务人员参考。例如，某些 ID 为 1PL、5PL、12PL 和 15PL。由于连接到连接器的 2 针电缆数量众多，因此在断开电缆之前记录电缆的连接位置非常重要。在断开电缆之前，请在电缆上标记它所连接的连接器的 ID。然后，当您准备连接更换板上的电缆时，任务会快速而准确。如果将 2 针电缆连接到错误的连接器，则在尝试启动驱动器之前，您可能不会意识到错误。这会导致变频器停机时间增加，变频器和现场执行的其他相关活动的生产率下降。

要从接线盒上拆下信号线，请随身携带一把窄的平头螺丝刀。松开固定螺钉并拉出信号线。确保信号线从电线末端去除约 0.5 英寸的绝缘层。最佳做法是将所有裸线插入端子。但是，如果去除的绝缘层小于 0.5 英寸，则可能无法在端子和信号线之间建立连接。

DS200FCRRG1AKD 点火电路控制板 GE  高精度温度控制

Product description

The GE ignition circuit control board DS200FCRRG1AKD has 1 terminal with terminals for 95 signal wires. It also contains 10 2-pin connectors, 2 ribbon cables, and a programmable logic device. The ID of the 10 2-pin connectors begins with a number and ends with a PL. These numbers are assigned sequentially and printed on the board surface for easy reference by installers or service personnel. For example, some ids are 1PL, 5PL, 12PL, and 15PL. Due to the large number of 2-pin cables connected to the connector, it is important to record where the cable is connected before disconnecting it. Before disconnecting the cable, mark the ID of the connector to which it is connected. Then, when you are ready to connect the cable on the replacement board, the task is quick and accurate. If you connect a 2-pin cable to the wrong connector, you may not realize the error until you try to start the drive. This results in increased drive downtime and reduced productivity for drives and other related activities performed on site.

To remove the signal cable from the junction box, carry a narrow flathead screwdriver with you. Loosen the screws and pull out the signal cable. Make sure the signal cable removes about 0.5 inches of insulation from the end of the wire. The best practice is to insert all bare wires into the terminal. However, if the insulation layer removed is less than 0.5 inches, it may not be possible to establish a connection between the terminal and the signal line.
