产品描述

DS200PCCAG5ACB是由通用电气创建的电源连接卡 （PCCA）。GE不再为该板提供任何类型的支持，并且变得有点难以定位。但是，AX Control 确实会尽一切努力保持该板的库存。

该DS200PCCAG5ACB被创建为SCR电源桥和驱动器控制电路之间的通道。它使用脉冲变压器将栅极驱动馈送到 SCR 电桥。该板被归类为高马力 PCCA，应与高 HP 控制器一起使用，因为它消除了所有缓冲器并将它们放置在系统的其他位置。除了没有缓冲器外，该板还消除了衰减字符串的使用。PCCA 上有 12 个插头连接器，PCCA 可以使用这些连接器将正向和反向的栅极脉冲信号发送到 SCR 桥。它还可以使用另一个插头连接器与电源板进行通信。本系统应使用的电源板是DCFB型板。该 PCCA 还使用 Leg 电抗器和保险丝。它使用单独的或公共母线变压器。

DS200PCCAG5ACB总共使用 4 个跳线。它们被标记为 WP4、WP3、JP2 和 JP1。该板位于电源板后面的驱动器控制后面。PCCA用这两块板固定在板载体的背面。有 6 个塑料支架可将其固定在托架中。

GE DS200PCCAG5ACB 电源连接卡 PLC控制器燃机

Product description

The DS200PCCAG5ACB is a Power connection card (PCCA) created by General Electric. GE no longer provided any type of support for the board, and it became a bit harder to locate. AX Control does, however, make every effort to keep the board in stock.

The DS200PCCAG5ACB is created as a channel between the SCR power bridge and the driver control circuit. It uses a pulse transformer to feed the gate drive to the SCR bridge. The board is classified as a high-horsepower PCCA and should be used with a high-HP controller because it eliminates all buffers and places them elsewhere in the system. In addition to having no buffer, the board also eliminates the use of attenuating strings. There are 12 plug connectors on the PCCA, which the PCCA can use to send forward and reverse gate pulse signals to the SCR bridge. It can also communicate with the power strip using another plug connector. The power supply board used in this system is DCFB type board. The PCCA also uses Leg reactors and fuses. It uses a single or common bus transformer.

The DS200PCCAG5ACB uses a total of four jumpers. They are labeled WP4, WP3, JP2, and JP1. The board is located behind the drive control behind the power board. The PCCA is fixed to the back of the plate carrier with these two plates. There are 6 plastic brackets to hold it in the bracket.
