GE DS200SSBCG1A 驱动器的缓冲板

GE DS200SSBCG1A 驱动器的缓冲板

产品描述

DS200SSBCG1A是用于DC300/2000通用电气驱动器的缓冲板。该板最初是作为Speedtronic Mark V涡轮机控制系统的一部分而创建的。它不再从GE获得任何类型的支持，并且可能有点难以找到。AX Control 确实会尽一切努力保持此板的库存。请立即与我们联系，以获取有关其可用性，价格和运输选项的信息。

DS200SSBCG1A是一种缓冲卡，也称为继电器板。该卡是一个多输入和输出系统，拥有板载 RAM。

DS200SSBCG1A是矩形印刷电路板.电路板的四个角上都有工厂钻孔，可用于安装它.底部边缘是两排绿色端子条。左侧的端子条以字母数字形式标记为 OT1 到 OT7。右侧的端子条标记为 IN1 到 IN7。在条带内的每个标记部分上都有一个三根电线的位置，并且有指示正电荷或负电荷的标签。在左侧，略高于端子条的是七个大的红色压敏电阻。压敏电阻上方是一个 26 引脚公头连接。右侧端子条上方是一组八个橙色小压敏电阻，它们与一组八个晶体管平行运行。稍高于此值的是八个蓝色电容器和八个集成电路。

GE DS200SSBCG1A 驱动器的缓冲板

Product description

The DS200SSBCG1A is a buffer board for DC300/2000 General Electric drives. The board was originally created as part of the Speedtronic Mark V turbine control system. It no longer gets any kind of support from GE and can be a little hard to find. AX Control does make every effort to keep this board in stock. Please contact us today for information on their availability, pricing and shipping options.

The DS200SSBCG1A is a buffer card, also known as a relay board. The card is a multi-input and output system with on-board RAM.

The DS200SSBCG1A is a rectangular printed circuit board. There are factory holes in all four corners of the board that can be used to mount it. The bottom edge is two rows of green terminal strips. The terminal bars on the left are labeled as OT1 through OT7 in alphanumeric form. The terminal strips on the right are labeled IN1 through IN7. There is a position of three wires on each marked section within the strip, and there are labels indicating positive or negative charges. On the left, slightly above the terminal strip, are seven large red varistors. Above the varistor is a 26-pin male head connection. Above the right terminal strip is a group of eight small orange varistors that run parallel to a group of eight transistors. Slightly above this value are eight blue capacitors and eight integrated circuits.
