GE DS200STBAG1ACB 基本驱动端子板

GE DS200STBAG1ACB 基本驱动端子板

产品描述

GE基本驱动端子板DS200STBAG1ACB为I/O信号提供连接点。DS200STBAG1ACB上有多个 I/O 连接。 该板通过连接器 6PL 和 8PL 连接到驱动控制板，通过 4PL 连接到直流电源，并通过串行端口作为用于配置、故障排除和诊断的用户界面。

DS200STBAG1ACB通过锁紧垫圈和支座柱固定在驱动器中，可将板固定到位。卸下主板时，请注意不要将锁紧垫圈掉落在电路板或驱动器上。锁紧垫圈可能会损坏组件。

在丢弃有缺陷的电路板之前，必须将旧电路板的所有跳线转移到新电路板。必须注意准确传输跳线以复制电路板的配置和行为。

此外，当您取出旧板时，必须小心保持水平并用两只手握住它。防止电路板撞击机柜中的其他板或组件以及机柜中的结构。

从主板上拔下电缆时，可能会损坏电缆。如果必须断开带状电缆，请用一只手握住电路板上的连接器。用另一只手握住带状电缆上的连接器并将它们拉开。请勿尝试通过握住带状电缆而不是连接器来拉出带状电缆。这可能会损坏带状电缆。某些电缆使用闩锁固定，以将电缆连接器锁定到位。按下闩锁将其解锁并拔出电缆连接器。

GE DS200STBAG1ACB 基本驱动端子板

Product description

The GE basic driver terminal board DS200STBAG1ACB provides a connection point for I/O signals. There are multiple I/O connections on the DS200STBAG1ACB. The board is connected to the drive control board via connectors 6PL and 8PL, to the DC power supply via 4PL, and to the serial port as a user interface for configuration, troubleshooting, and diagnosis.

The DS200STBAG1ACB is secured in the drive by locking washers and support posts to hold the plate in place. When removing the motherboard, be careful not to drop the lock washer on the circuit board or driver. The lock washer may damage the component.

Before discarding a defective board, all jumpers from the old board must be transferred to the new board. Care must be taken to transmit jumpers accurately to replicate the configuration and behavior of the board.

Also, when you remove the old board, you must be careful to keep it level and hold it with both hands. Prevent the circuit board from hitting other boards or components in the cabinet and the structure in the cabinet.

Removing the cable from the motherboard may damage the cable. If you must disconnect the ribbon cable, hold the connector on the circuit board with one hand. Hold the connectors on the ribbon cable with your other hand and pull them apart. Do not attempt to pull out the ribbon cable by holding it instead of the connector. This may damage the ribbon cable. Some cables are secured with latches to lock the cable connector in place. Press the latch to unlock it and pull out the cable connector.
