GE DS200TBCG1ATERM 连接器继电器端子板

GE DS200TBCG1ATERM 连接器继电器端子板

GE 连接器继电器端子板 DS200DTBCGIA 具有 2 个接线端子，每个接线端子可连接 110 根信号线。它还包含 2 个 3 线卡口连接器和 1 个 2 线卡口连接器和 10 个跳线。

该板高 3 英寸，长 11.5 英寸。驱动器内部有空间可用于安装电路板。由于板上可以连接 220 根信号线，因此将它安装在信号线可以正确布线的位置非常重要。由于存在干扰的风险，信号线不能靠近电源线布线。电源线被认为是有噪声的，这意味着它们会辐射信号噪声，这会干扰电路板接收到的信号的准确性。它们还会干扰电路板接收到的信号。有时可以使用屏蔽线来屏蔽干扰。但是，最好的解决方案是将电源线与信号线分开布线。如果必须将它们布线在一起，最好限制它们捆绑在一起的布线长度。

布置信号线，使其不会干扰驱动器内部的气流。驱动器的设计使冷空气通过通风孔从驱动器底部进入驱动器。空气流过加热的组件并通过驱动器顶部的通风口带走热量。

GE DS200TBCG1ATERM 连接器继电器端子板

The GE Connector Relay terminal board DS200DTBCGIA has 2 terminals, each of which can connect 110 signal cables. It also contains 2 3-wire bayonet connectors and 1 2-wire bayonet connector and 10 jumpers.

The board is 3 inches high and 11.5 inches long. There is space inside the driver for mounting the circuit board. Since 220 signal wires can be connected to the board, it is important to install it in a position where the signal wires can be routed correctly. Because of the risk of interference, the signal line should not be near the power cable wiring. Power lines are considered noisy, which means they radiate signal noise, which interferes with the accuracy of the signal received by the board. They can also interfere with the signals received by the board. Sometimes a shielded wire can be used to block out interference. However, the best solution is to route the power cord separately from the signal line. If they must be wired together, it is best to limit the length of wiring they are bundled together.

Lay out signal lines so that they do not interfere with the airflow inside the driver. The drive is designed so that cold air enters the drive from the bottom through a vent hole. Air flows through the heated components and carries the heat away through vents at the top of the drive.
