DS200TBPAG1A GE 用于低电平信号的端接板

DS200TBPAG1A GE 用于低电平信号的端接板

产品描述

DS200TBPAG1A是 Mark V 板组件。它的制造适合GE分销的后来的Speedtronic系统之一，该系统旨在管理燃气轮机和蒸汽轮机。Speedtronic系列始于1960年代MKI的发布，并在1990年代继续发展。虽然 GE 不再提供 MKV 组件，但它们可以通过 AX Control 作为优化和经过全面测试的翻新硬件购买。请注意，DS200 系列主板不包含更新的固件;如果您的系统需要这样做，请在我们的网站上搜索类似的DS215系列板。

DS200TBPAG1A用作低电平信号的端接板。它通常用于 EX2000 励磁系统。该电路板又窄又长， 在两条背靠背的线路中填充电路板一侧的四个端子条.该板还具有 <> 个晶体管、<> 个垂直引脚电缆连接器、<> 个电阻网络阵列和 <> 个跳线开关。该板具有 <> 个金属氧化物压敏电阻以及其他电容器、电阻器和二极管。电路板组件通常标有参考标志和/或其原始制造商代码。电路板至少在三个地方钻孔。这些钻孔用导电材料包围。

DS200TBPAG1A GE 用于低电平信号的端接板

Product description

The DS200TBPAG1A is a Mark V board component. It was built to fit into one of the later Speedtronic systems distributed by GE, which was designed to manage gas and steam turbines. The Speedtronic series began with the release of the MKI in the 1960s and continued to evolve in the 1990s. While GE no longer offers MKV components, they can be purchased as optimized and fully tested refurbished hardware through AX Control. Please note that DS200 series motherboards do not include updated firmware; If your system requires this, please search for similar DS215 series boards on our website.

The DS200TBPAG1A is used as an end board for low-level signals. It is commonly used in EX2000 excitation systems. The board is narrow and long, with four terminal strips on one side of the board filled in two back-to-back lines. The board also has <> a transistor, <> a vertical pin cable connector, <> a resistance network array, and <> a jumper switch. The plate has <> metal-oxide varistors as well as other capacitors, resistors and diodes. Board components are usually marked with a reference logo and/or their original manufacturer code. The circuit board is drilled in at least three places. The holes are surrounded by conductive material.

DS200TBPAG1A GE 用于低电平信号的端接板
