产品描述

GE RST 溢出板DS200TCQCG1ADB装有 24 个跳线和 3 个 40 针连接器。它还具有 3 个 34 针连接器和 1 个 16 针连接器。分配给 16 针连接器的 ID 是 JC。分配给 40 针连接器的 ID 是 JFF、JE 和 6PL。 该板还具有 2 个 3 针连接器。3 针连接器的 ID 是 VARC 和 JX。当您计划更换 GE RST 溢出板DS200TCQCG1ADB时，连接器 ID 非常有用。要安装新板并确保其性能与要更换的板完全相同，有必要将电缆连接到相同的连接器。当多根电缆连接到电路板时，在断开电缆之前，您必须识别电缆以了解它们在要更换的电路板上的连接位置。使用可以临时连接到电缆的遮蔽胶带或贴纸条，并记下其所连接的连接器的 ID。

您可能会发现新主板是主板的更高版本，并且连接器位于不同的位置。这是为了适应电路设计的变化。它可能具有看起来不同的组件。但是，尽管存在差异，但董事会将运行相同。由于在许多不同的环境中进行了产品测试，您可以确保电路板已经过测试并验证其将以相同的方式运行。安装人员还必须设置跳线以匹配要更换的电路板上设置的位置。

GE DS200TCQCG1ADB 模拟输入输出模块 自动化

Product description

The GE RST overflow board DS200TCQCG1ADB is equipped with 24 jumpers and 3 40-pin connectors. It also features three 34-pin connectors and one 16-pin connector. The ID assigned to the 16-pin connector is JC. The ids assigned to 40-pin connectors are JFF, JE, and 6PL. The board also has 2 3-pin connectors. The ids of the 3-pin connectors are VARC and JX. The connector ID is useful when you plan to replace the GE RST overflow board DS200TCQCG1ADB. To install the new board and ensure that its performance is exactly the same as the board to be replaced, it is necessary to connect the cable to the same connector. When multiple cables are connected to the board, you must identify the cables to know where they are connected on the board to be replaced before disconnecting the cables. Use masking tape or sticker strips that can be temporarily attached to the cable and note the ID of the connector to which it is attached.

You may find that the new motherboard is a higher version of the motherboard and that the connectors are located in a different location. This is to accommodate changes in circuit design. It may have components that look different. But despite the differences, the board will run the same. Since product testing is done in many different environments, you can be sure that the board has been tested and verify that it will operate the same way. The installer must also set the jumper to match the position set on the board to be replaced.
