产品描述

DS200TCSAG1A型号是通用电气制造的Mark V系列的电路板部分。此型号标记为UC压力传感器接口或燃油撬块接口板。当该模型在 R 内核中使用时，它将与安装在 R2 内核中的 XDSA 板接口;该模型将与具有干式低排放 （DLE） 功能的燃油橇上的 XDSA 板连接。TCSA 板将解码来自 UCIB 板上 196 处理器的高分辨率压力传感器的信号。来自 TCSA 板的信号将从 XDSA 板读取。从XDSA板接收到的信号将发送到Mark V系统内的TBSA终端板，然后通过DS3TCSAG200A型号上的P1连接器传输到TCSA板。

当DS200TCSAG1A模型用作压力传感器接口模型时，TCSA 板将解码来自 RS422 连接器的协议信号，并将其写入 UCIB 板以供 196 处理器处理。TCSA板还可以为压力传感器和FMVED电机控制器供电。

TCSA 型号上有五个主要连接器。连接器是 2PL，这是来自 R 芯中 TCPS 板的电源;SER 连接器将解码的压力传感器信号写入 UCIB 板;P3 和 P4 连接器都将为 TBSA 提供 12 VDC 电源;P4 连接器将连接到 FMVED 电机控制器，P4 连接器将接收来自 TBSA 的压力信号，以连接到燃油撬块上的 XDSA 板，以及 GND 连接器（即机箱接地到 R 内核中的 1TB 端子板）。

GE DS200TCSAG1A UC压力传感器接口

Product description

The DS200TCSAG1A model is part of the Mark V series circuit board manufactured by General Electric. This model is labeled UC pressure sensor interface or fuel skid interface board. When the model is used in the R kernel, it interfaces with the XDSA board installed in the R2 kernel; The model will be connected to an XDSA board on a fuel sled with dry low emission (DLE) functionality. The TCSA board will decode the signal from the high-resolution pressure sensor on the 196 processor on the UCIB board. The signal from the TCSA board will be read from the XDSA board. The signal received from the XDSA board is sent to the TBSA terminal board within the Mark V system and then transmitted to the TCSA board via the P1 connector on the DS3TCSAG200A model.

When the DS200TCSAG1A model is used as the pressure sensor interface model, the TCSA board decodes the protocol signal from the RS422 connector and writes it to the UCIB board for processing by the 196 processor. The TCSA board can also power pressure sensors and FMVED motor controllers.

There are five main connectors on the TCSA model. The connector is 2PL, which is the power supply from the TCPS board in the R core; The SER connector writes the decoded pressure sensor signal to the UCIB board; Both the P3 and P4 connectors will provide 12 VDC power to the TBSA; The P4 connector will be connected to the FMVED motor controller, the P4 connector will receive pressure signals from TBSA to connect to the XDSA board on the fuel pry, and the GND connector (i.e. the 1TB terminal board in the case grounded to the R core).
