GE DS200UPLAG1ABA 励磁IGCT可控硅

GE DS200UPLAG1ABA 励磁IGCT可控硅

产品描述

GE LAN电源电路板DS200UPLAG1ABA包含一对26针连接器，1个保险丝和1个拨动开关。该板还有一个复位按钮和一个 8 针连接器。GE LAN电源电路板DS200UPLAG1ABA装有开关，使您能够修改电路板的行为。板上有两个开关块，每个块包含八个开关。有关每个交换机使用的更多信息，请参阅主板随附的文档。但是，当您安装更换板时，最好只是将旧板上的开关设置与更换板上的开关一起模拟。

要更改开关的位置，请考虑当驱动器中通电时无法更改开关的位置。最好在将主板安装到驱动器中之前移动开关。将旧板和替换板彼此相邻，并比较开关的设置。

使用更换板时，请佩戴腕带，并将更换板放在保护袋顶部。使用一根手指或一个小工具移动开关。移动开关时，不要损坏电路板上的任何组件，这一点很重要。如果计划使用工具移动开关，请用一只手握住工具，另一只手将工具引导到开关上。

GE DS200UPLAG1ABA 励磁IGCT可控硅

Product description

The GE LAN power circuit board DS200UPLAG1ABA contains a pair of 26-pin connectors, a fuse, and a toggle switch. The board also has a reset button and an 8-pin connector. The GE LAN power board DS200UPLAG1ABA is equipped with switches that allow you to modify the behavior of the board. There are two switch blocks on the board, each containing eight switches. For more information on the use of each switch, see the documentation that came with the motherboard. However, when you install a replacement board, it is best to just simulate the switch Settings on the old board along with the switches on the replacement board.

To change the position of the switch, consider that you cannot change the position of the switch when power is on in the drive. It is best to move the switch before installing the motherboard into the drive. Place the old board and replacement board next to each other and compare the Settings of the switch.

When using the replacement board, wear a wristband and place the replacement board on top of the protective bag. Use a finger or a small tool to move the switch. When moving the switch, it is important not to damage any components on the board. If you plan to use the tool to move the switch, hold the tool with one hand and guide the tool to the switch with the other.

GE DS200UPLAG1ABA 励磁IGCT可控硅
