DS2020DACAG2模块的功能是将VAC电源转换为VDC电源。电源转换为 125 VDC 后，二极管将耦合到控制器内的其他 DC 电源以创建 DC 总线，然后为任何控制器模块以及连接到模块的门脉冲放大器板供电。

连接到 DACA 模块的 EPDM、EGPA、EXTV 和 EPBP 等输出都有 LED 指示灯，用于指示为 DS2020DACAG2 提供的电源是否正确。重要的是要注意，当二极管耦合在一起并且模型的接地居中时，设备的接地电压标称读数应为 +62.5 和 -62.5 伏。

操作 DACA 设备时最好使用的手册是 GEH-6632 EX2100 用户指南和 GEH-6721L PDM 配电模块系统指南。

DS2020DACAG2 模块是一个向后兼容的系统，应该用作 DS2020DACAG1 模块的替换部件。 当一个或可能两个 DACA 模块连接到 IS2020JPDF 时，交流电流将通过位于 JPDF 和 JPDB 之间的线束提供。

GE DS2020DACAG2 工控燃机卡件设备

The function of the DS2020DACAG2 module is to convert VAC power to VDC power. After the power is converted to 125 VDC, the diodes are coupled to other DC power supplies within the controller to create a DC bus, which then powers any controller module as well as the gate pulse amplifier board connected to the module.

The outputs such as EPDM, EGPA, EXTV and EPBP connected to the DACA module have LED indicators to indicate whether the power supply to the DS2020DACAG2 is correct. It is important to note that when the diodes are coupled together and the ground of the model is centered, the nominal ground voltage readings for the device should be +62.5 and -62.5 volts.

The best manuals to use when operating DACA equipment are the GEH-6632 EX2100 User Guide and the GEH-6721L PDM Power Distribution Module System Guide.

The DS2020DACAG2 module is a backward compatible system and should be used as a replacement for the DS2020DACAG1 module. When one or possibly two DACA modules are connected to the IS2020JPDF, AC current will be provided through a wire harness located between the JPDF and the JPDB.
