GE DS2020FECNRX010A 具有7个跳线和2个接线端子

GE DS2020FECNRX010A 具有7个跳线和2个接线端子

产品描述

GE励磁板DS2020FECNRX010A具有7个跳线和2个接线端子，每个接线端子上有3个端子。跳线标识为 JP1 到 JP7。GE线路保护板DS2020FECNRX010A还包含多个插脚型连接器。该板安装在驱动器另一个组件的支架上。连接到电路板的信号线源自其所连接的组件。

电路板及其连接的组件产生热量，设计用于连接到高压电流。因此，变频器必须位于空气自由流动的环境中，该环境可以冷却变频器和内部组件。安装驱动器后，您会注意到驱动器是否保持冷却，或者驱动器温度是否使其达到高温阈值并自动关闭。

首先注意驱动器是否会被其他产生热量的设备包围，并确定这些设备是否太近。即使设备产生热量，您也可以为加热的空气留出空间。您可能确定驱动器和其他设备之间需要风扇。确保风扇移动足够的空气并处于良好的工作状态以保持服务状态。在某些情况下，烟罩用于收集加热的空气并将其排出环境。确保引擎盖清洁且足够大以按预期运行。

GE DS2020FECNRX010A 具有7个跳线和2个接线端子

Product description

The GE exciter DS2020FECNRX010A has 7 jumpers and 2 terminals, with 3 terminals on each terminal. The jumper is labeled JP1 through JP7. The GE line protection board DS2020FECNRX010A also contains a number of pin type connectors. The board is mounted on the bracket of another component of the drive. The signal wires connected to the board are derived from the components to which they are connected.

The circuit board and its connected components generate heat and are designed to be connected to high voltage currents. Therefore, the inverter must be located in an environment with free air flow, which can cool the inverter and the internal components. After installing the drive, you will notice if the drive stays cool, or if the drive temperature brings it to a high temperature threshold and automatically shuts down.

Start by noticing if the drive will be surrounded by other heat-generating devices, and determine if these devices are too close. Even if the device generates heat, you can leave room for heated air. You may determine that a fan is needed between the drive and other devices. Make sure the fan moves enough air and is in good working condition to maintain service. In some cases, smoke hoods are used to collect heated air and expel it from the environment. Make sure the hood is clean and large enough to operate as intended.

GE DS2020FECNRX010A 具有7个跳线和2个接线端子
