GE DS215KLDCG1AZZ03A 输入隔离端子板

GE DS215KLDCG1AZZ03A 输入隔离端子板

产品描述

DS215KLDCG1AZZ03A是通用电气为其Speedtronic Mark V涡轮机控制系统创建的PC板。

DS215KLDCG1AZZ03A是一块大型印刷电路板。它重约 1.07 磅。

有许多组件组成了DS215KLDCG1AZZ03A。在板的角落和侧面的中心有工厂钻孔。这些孔可用于帮助安装电路板。在电路板的顶部是一个小的黄色电容器和一个较大的黄色电容器。有二十一个不可分割的组件，构成了董事会顶部的大部分。电路板上半部分有六个集成电路，三个黄色电阻网络和两个额外的黄色电容器。该板的中间和下半部分共有 32 个白色显示灯。电路板的右中侧有一个感应线圈，其左侧和右侧都有一个晶体管。在电路板的下半部分是十二个集成电路和两个EPROM。电路板下半部分还有 40 个黄色电阻网络。该板的下半部分有六个大电阻和许多二极管。电路板底部有三个继电器和一个 <> 针公连接器。

GE DS215KLDCG1AZZ03A 输入隔离端子板

Product description

The DS215KLDCG1AZZ03A is a PC board created by General Electric for its Speedtronic Mark V turbine control system.

The DS215KLDCG1AZZ03A is a large printed circuit board. It weighs about 1.07 pounds.

There are many components that make up DS215KLDCG1AZZ03A. There are factory holes in the corners and centers of the sides of the board. These holes can be used to help mount the circuit board. At the top of the board are a small yellow capacitor and a larger yellow capacitor. There are twenty-one indivisible components that make up the majority of the top of the board. The upper half of the board has six integrated circuits, three yellow resistance networks, and two additional yellow capacitors. There are 32 white display lights in the middle and bottom half of the board. There is an induction coil on the right center side of the board, and a transistor on the left and right sides. On the bottom half of the board are twelve integrated circuits and two EPROMs. There are also 40 yellow resistance networks on the bottom half of the board. The lower half of the board has six large resistors and many diodes. On the bottom of the board are three relays and a <> pin male connector.
