产品描述

被称为DS215SLCCG2AZZ01B的印刷电路板是通用电气Mark V涡轮机控制系统可用的几种LAN通信卡之一。 GE制造的SLCC板有三种不同版本：SLCCG1A板，SLCCG2A板和SLCCG4A板。请务必为您的系统订购正确的配置。该板包括仅用于将驱动器连接到 DLAN 网络的电路。如果您需要连接到 ARCNET，请查看该板SLCCG1A版本。

DS215SLCCG2AZZ01B板在 Mark V 系统中与 SDCC 驱动控制卡配合使用。 SLCC 板上的主处理器是位于 U1 的 LAN 控制处理器。电路板软件存储在可更换的EPROM中。这些位于U6和U7。虽然该板不可通过软件配置，但这些EPROM可以移动或更换。同时，用于通信和专用RAM的RAM位于U5，U8和U9。硬件配置包括跳线和多个跳线开关。

DS215SLCCG2AZZ01B板通常使用四个支架连接到 SLCC 卡上的四个工厂钻孔中，安装在 SDCC 板上。

其他电路板组件包括电阻网络阵列、电阻器、电容器、垂直引脚连接器和多位字母数字显示器。

GE DS215SLCCG2AZZ01B 超高速光纤反射内存

Product description

The printed circuit board, known as the DS215SLCCG2AZZ01B, is one of several LAN communication cards available for the GE Mark V turbine control system. GE manufactures SLCC boards in three different versions: SLCCG1A board, SLCCG2A board and SLCCG4A board. Be sure to order the correct configuration for your system. The board includes circuits that are only used to connect the driver to the DLAN network. If you need to connect to ARCNET, check out the SLCCG1A version of the board.

The DS215SLCCG2AZZ01B board is used in conjunction with the SDCC drive control card in the Mark V system. The main processor on the SLCC board is the LAN control processor located in U1. The board software is stored in a replaceable EPROM. These are located at U6 and U7. Although the board cannot be configured via software, these EPROMs can be moved or replaced. Meanwhile, the RAM for communication and dedicated RAM is located at U5, U8 and U9. Hardware configuration includes jumpers and multiple jumper switches.

The DS215SLCCG2AZZ01B board is usually mounted on the SDCC board using four brackets attached to four factory boreholes on the SLCC card.

Other board components include resistor network arrays, resistors, capacitors, vertical pin connectors, and multi-digit alphanumeric displays.
