产品描述

IC693PCM300 产品描述 是4 A隔离继电器输出模块。该模块为90-30系列可编程逻辑控制器设计，提供8个常开继电器电路。这些使用户能够控制输出负载。 每个电路具有4安培的输出开关容量。模块上的每个输出点都与其他点隔离，并且每个点都有单独的公共电源输出端子。

继电器输出模块能够控制各种负载设备。这包括但不限于指示器，电动机启动器和螺线管。要操作连接到该模块的现场设备，用户需要提供交流或直流电源。  在模块的顶部，有两排水平的绿色LED，用于指示每个点的ON / OFF状态。每行有八个LED。由于IC693MDL930仅具有8个继电器电路，因此不使用底行。第一行标记为A1，指示点1到8的状态。

在模块上的铰链门的内表面和外表面之间有一个插件。在左外边缘，插入物被标记为红色。这表明它是高压模块。当门关闭时，面向模块内部的内表面具有电路布线信息。在外表面上，可以记录电路标识信息。想要为工业应用实现此模块的用户可以使用任何90-30系列PLC系统来实现。继电器输出模块可以安装在5插槽或10插槽底板的任何I / O插槽中。

IC693PCM300R  GE 模块上每个输出点与其他点隔离

Product description

The IC693PCM300 product description is A 4 A isolation relay output module. The module is designed for the 90-30 series of programmable logic controllers and provides 8 normally open relay circuits. These enable the user to control the output load. Each circuit has an output switching capacity of 4 amps. Each output point on the module is isolated from the others, and each point has a separate common power output terminal.

The relay output module can control various load devices. This includes, but is not limited to, indicators, motor starters and solenoids. To operate field devices connected to the module, the user needs to provide AC or DC power. At the top of the module, there are two horizontal rows of green leds that indicate the ON/OFF status of each point. Each row has eight leds. Since the IC693MDL930 has only eight relay circuits, the bottom line is not used. The first line, labeled A1, indicates the status of points 1 through 8.

There is a plug-in between the inner and outer surfaces of the hinged door on the module. On the left outer edge, inserts are marked in red. That means it's a high-voltage module. When the door is closed, the inner surface facing the inside of the module has circuit routing information. On the exterior surface, circuit identification information can be recorded. Users who want to implement this module for industrial applications can do so using any 90-30 series PLC system. The relay output module can be installed in any of the I/O slots on the 5 - or 10-slot baseboards.
