产品描述

DS215TCQBG1BZZ01A是用于Mark V系列系统的GE电路板。该板现在是遗留系列的一部分，可能很难找到。AX Control 确实尝试将此板作为新的剩余或翻新库存部件保留在库存中。请直接与我们联系，以获取有关其可用性，价格和运输选项的更多信息。

DS215TCQBG1BZZ01A是一个大的矩形印刷电路板 （PCB），在四个角中的每个角上都有一个工厂钻孔，在每个板边缘的中心都有一个。这些孔可用于帮助安装电路板。该板可以安装在 Mark V 硬件机柜内的卡架中。该主板附带固件。

DS215TCQBG1BZZ01A上有许多不同的组件。在电路板的底部边缘是四个不同的公引脚连接端口。在电路板的左下角是九个集成电路，周围环绕着黄色小电容器。九个集成电路上方是九个电阻器、六个红色跳线和九个红色电阻网络。电阻网络上方是另一组集成电路和电容器。还有七个电阻器和九个电阻网络。上面是另外14个被黄色电容器包围的集成电路。在电路板的顶部边缘，集成电路旁边和上方有两个EPROM，位于四个继电器旁边和上方。继电器下方还有 12 个集成电路，周围有二极管，另外两个 EPROM，<> 个黄色电阻网络和另外两个 FPGA。

GE DS215TCQBG1BZZ01A 是一个大的矩形印刷电路板

Product description

The DS215TCQBG1BZZ01A is a GE board for Mark V series systems. The board is now part of the legacy series and may be difficult to find. AX Control did attempt to keep this board in inventory as a new surplus or refurbished stock part. Please contact us directly for more information on their availability, pricing and shipping options.

The DS215TCQBG1BZZ01A is a large rectangular printed circuit board (PCB) with a factory drill hole in each of the four corners and one in the center of each board edge. These holes can be used to help mount the circuit board. The board can be installed in the card holder in the Mark V hardware cabinet. The motherboard comes with firmware.

There are many different components on the DS215TCQBG1BZZ01A. On the bottom edge of the board are four different male pin connection ports. In the lower left corner of the board are nine integrated circuits surrounded by small yellow capacitors. Above the nine integrated circuits are nine resistors, six red jumpers, and nine red resistor networks. Above the resistance network is another set of integrated circuits and capacitors. There are also seven resistors and nine resistance networks. Above are 14 more integrated circuits surrounded by yellow capacitors. On the top edge of the board, next to and above the integrated circuit, there are two EPROMs located next to and above the four relays. There are also 12 integrated circuits below the relay, surrounded by diodes, two more EPROMs, <> a yellow resistor network, and two more FPGas.
