产品描述

DS215TCQFG1AZZ01A是GE Speedtronic Mark V TCQF <Q>核心PCB。此主板附带固件，但不再受 GE 支持。AX Control 会尽力保持库存，但请直接与我们联系以了解其可用性和价格。

DS215TCQFG1AZZ01A是为Mark V涡轮机控制系统制成的大型矩形印刷电路板。该板不是控制系统的标准配置。它是一种可选板，能够取代 TCQB 板。

DS215TCQFG1AZZ01A有许多组件。有五个公引脚连接器，分别具有 50、40、36 和两个 34 引脚连接。该板上有两个 EPROM。在左下角，该板包含 24 个集成电路、45 个黄色小电容器、24 个红色电阻网络阵列、2 个橙色条纹电阻器、6 个深蓝色电阻器、2 个晶体管和 2 个黄色大矩形电阻器。在左上角，该板有 8 个蓝色大矩形电阻器、23 个橙色条纹电阻器、10 个深蓝色电阻器、6 个黄色电阻器网络阵列、7 个红色电阻器网络阵列、7 个跳线、34 个黄色小电容器、6 个晶体管和 17 个白色电阻器。在电路板的右顶端是 8 个黄色电阻网络阵列、48 个黄色矩形电阻、4 个黄色电容器、4 个小白色电容器、13 个红色电阻网络、一个继电器、8 个集成电路和 22 个蓝色电阻。在电路板的右下角，有 15 个集成电路、15 个橙色条纹电阻器、37 个深蓝色电阻器、一个跳线、一个振荡器、5 个黄色电容器、4 个浅蓝色电阻器和 <> 个黄色电阻网络。

DS215TCQFG1AZZ01A 是一种可选板能够取代 TCQB 板

Product description

The DS215TCQFG1AZZ01A is a GE Speedtronic Mark V TCQF <Q> core PCB. This motherboard comes with firmware, but is no longer supported by GE. AX Control will do its best to keep stock, but please contact us directly for availability and prices.

The DS215TCQFG1AZZ01A is a large rectangular printed circuit board made for the Mark V turbine control system. This board is not standard for the control system. It is an optional board that can replace the TCQB board.

The DS215TCQFG1AZZ01A has many components. There are five male pin connectors with 50, 40, 36, and two 34-pin connections. There are two EPROMs on the board. In the lower left corner, the board contains 24 integrated circuits, 45 small yellow capacitors, 24 red resistor network arrays, 2 orange stripe resistors, 6 dark blue resistors, 2 transistors, and 2 large yellow rectangular resistors. In the upper left corner, the board has 8 large blue rectangular resistors, 23 orange striped resistors, 10 dark blue resistors, 6 yellow resistor network arrays, 7 red resistor network arrays, 7 jumpers, 34 small yellow capacitors, 6 transistors, and 17 white resistors. At the top right of the board are eight yellow resistance network arrays, 48 yellow rectangular resistors, four yellow capacitors, four small white capacitors, 13 red resistance networks, one relay, eight integrated circuits, and 22 blue resistors. In the bottom right corner of the board, there are 15 integrated circuits, 15 orange stripe resistors, 37 dark blue resistors, a jumper, an oscillator, 5 yellow capacitors, 4 light blue resistors, and <> a network of yellow resistors.
